Product description:
- Smart Temperature head transmitter for converting the input signal into a standard 4 to 20 mA analog output signal
- Input: Resistance thermometer (RTD) Pt100
- Measurement range can be easily adjust through dial switch using a small screw driver
| Input | |
| input signal |
B,E,J,K,N,R,S,T type thermocouple; PT50,PT100,PT1000,CU50,CU100 type thermal resistance;resistance,mV voltage input |
| output | |
| output | 4-20mA DC+Hart protocol digital communication(2-wire) |
| max load | max:(Vpower-10V)/0.022A(circuit output) |
| The cold end compensation accuracy | 0.5°C |
| damp | 0-32s |
| current limit | ≤22mA |
| saturation current | low 3.8mA;high 20.6mA |
| current alarm | output is 3.6mA or 22mA when sensor damage or break |
| response time | ≤0.8s |
| data fresh rate | 4 times/S |
| stability | ±0.1%/year |
| accuracy | ±0.1% |
| mechanical vibration | 10…60Hz,0.21mm sine wave |
| Rf interference | IEC6100-4-3,20V/M,80 100MHZ |
| Power supply | |
| voltage supply | U=10V-36VCD |
| electrical isolation | U=2000VAC |
| Environment Condition | |
| working temperature | -40...+85°C |
| keeping temperature | -40…+100°C |
| protection degree | IP66 |
YANTAI AUTO INSTRUMENT MAKING CO.,LTD.
Mainly produce differential pressure transmitter, pressure transmitter, capacitive pressure sensor, RF admittance controller, tuning fork, level meter, winding pressure transmitter, magnetostrictive level gauge etc.. Which are widely used in the industries of electrical power, petroleum, metallurgy, medicine, food, brewing, textile, and build material etc.. The performance of the company are quickly increased through stable development for more than ten years since 1994.
We adopt firstly in Shandong of the certification of ISO9001:2000 for the instrument company by Premier company in July,2001, and we build the quality management system which comply with the international approval.
Our company is authorized to be the China Marketing General Agent of ultrasonic range finder by the Bohr company from Germany.
Guarantee and after-sale service:
18 months guarantee for whole machine
24 hours technical support by e-mail.
