Cheap Pt100 Temperature Sensor Remote Temperature Transmitter

US$ 32 - 600 MOQ: 1 Piece

Key Specifications

Place of Origin:

Shandong, China

Brand Name:

OEM

Model Number:

pt100

Yantai AUTO Instrument Precision Casting Co., Ltd.

6Yrs

Payment & Shipping

Payment Methods:

Port of Shipment:

yantai

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Shandong, China

Brand Name OEM

Model Number pt100

Usage Other

Theory Other

Accuracy 1 C

Temperature Range -50 to 70

Product description:

Smart Temperature head transmitter for converting the input signal into a standard 4 to 20 mA analog output signal
Input: Resistance thermometer (RTD) Pt100
Measurement range can be easily adjust through dial switch using a small screw driver

Technical parameter:

Input
input signal	B,E,J,K,N,R,S,T type thermocouple; PT50,PT100,PT1000,CU50,CU100 type thermal resistance;resistance,mV voltage input
output
output	4-20mA DC+Hart protocol digital communication(2-wire)
max load	max:(Vpower-10V)/0.022A(circuit output)
The cold end compensation accuracy	0.5°C
damp	0-32s
current limit	≤22mA
saturation current	low 3.8mA;high 20.6mA
current alarm	output is 3.6mA or 22mA when sensor damage or break
response time	≤0.8s
data fresh rate	4 times/S
stability	±0.1%/year
accuracy	±0.1%
mechanical vibration	10…60Hz,0.21mm sine wave
Rf interference	IEC6100-4-3,20V/M,80 100MHZ
Power supply
voltage supply	U=10V-36VCD
electrical isolation	U=2000VAC
Environment Condition
working temperature	-40...+85°C
keeping temperature	-40…+100°C
protection degree	IP66
