Express Bus Moving Message Single Color P10 LED Outdoor Display Screen

Name: Express Bus Moving Message Single Color P10 LED Outdoor Display Screen
Brand: FOXGOLDEN
SKU: 122237187

US$ 600 - 1,000 MOQ: 2 Square Meters

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

FOXGOLDEN

Model Number:

Outdoor single-color dip p10 LED display

Foxgolden Technology Limited

Payment & Shipping

Payment Methods:

Port of Shipment:

Shengzhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name FOXGOLDEN

Model Number Outdoor single-color dip p10 LED display

Usage Outdoor

Tube Chip Color Other, yellow

Display Function Other, text

Pixels 10mm

The technology parameter of P10 outdoor
Number	Item	P10
1	Pixel pitch	10mm
2	Size of modual	160mm X 320mm
3	Resolution of modual	16X32
4	Density of pixel	10000dots/m2
5	Pixel configuration	1R1G1B
6	Red wavelength	625±2nm
7	Green wavelength	525±2nm
8	Blue wavelength	470±2nm
9	Colors	16777216
10	Best viewing distance	≥10m
11	Horizontal viewing angle	140°
12	Maximum power consumption	≤1100w/m 2
13	Brightness	≥9500cd /m 2
14	Gray scale	16bits per color
15	Color temperature	6500k
16	Control method	Synchronization & Asynchronization
17	Driving method	1/4scanning
18	Frame frequency	60Hz
19	Refresh frequency	≥450Hz
20	Working voltage	AC220V/110V±10%
21	IP grade	IP67(adjustable)
22	Working temperature	--20ºC-+80ºC
23	MTBF	>10000 hours
24	Life span	>100,000 hours
25	Defects rate.	≤0.00001(Led display line standard<0.0001)
26	Computer operation system	Win XP/Vista/ Win 2000/WIN7ect.
27	Video signal	RF, S-Video, RGB, RGBHV, YUV, YC.ect
