Full Color Rgb P10 Led Display Screen Outdoor Led Module With Wholesale Price $10.0/Pcs
- 1000 Piece / Pieces per Month
- Shenzhen port
- T/T Credit Card
- 60W UL CE LED Canopy Lamp with aluminum frame Ex-factory price from Shenzhen
- 80W Energy-Saving Gas Station LED Canopy Lamp hot sale from Shenzhen
- 60W UL CE Energy Saving LED Canopy Lamp with 3 years warranty from Shenzhen
- 2014 new design, led flood light, led Gas Station Lamp, LED canopy light 100w
- Led flood light, led Gas Station Lamp, LED canopy light 100w
- 120W High power cree led canopy lamp Wholesale from Shenzhen for gas staton
Product Details
Place of Origin: | Guangdong, China | Brand Name: | FOXGOLDEN | Model Number: | FOX-DIP-P10 |
Usage: | Outdoor | Tube Chip Color: | Full Color | Display Function: | Video |
Pixels: | 10mm | Screen Dimension: | Customized |
Product Description
Full Color Rgb P10 Led Display Screen Outdoor Led Module With Wholesale Price $10.0/Pcs
Specification:
Parameters | Value | Parameters | Value |
Model | P10 | Refresh Rate | ≥400HZ |
Pixel pitch | 10mm | Blind spot Rate | ≤0.01% |
Module Size(W×H) | 160x160mm | Gray scale per color | 65536 |
Module Resolution(W×H) | 16*16dots | IP Grade(Front/Rear) | IP65/IP54 |
Pixel Density | 10000dot/sqm. | Power consumption(max/avg) | 600 / 230W/sqm. |
Brightness | ≥7500nits | Input voltage(AC) | 110~240v |
Viewing angle(H/V) | 110° /70° | Operating temperature | -20°C~50°C |
Best Viewing Distance | 10-300m | Operating humidity | 10%~90% |
Delivery Time and packing:
1. Delivery time: Accomplish manufacturing within7- 15 days after receiving the deposit.
2.Before delivery, we will test the display, and keep it light up for 72 hours, and check all the parts of the display to confirm it is OK for delivery.
3.Package:(1)carton (2) anti-shaking wooden case (3) flight case
Trade Terms: |
|
Payment terms: | -Sample Charge: T/T or Western Union -Paypal; Western Union |
Packing: | -Standard Export Carton with fully Polyfoam or Pearl Wool |
Shipping: | -Delivery within 5 to 15 working days upon receiving deposit payment |
After-Sales-Service: | -Lifetime with professional engineer support. problem |
On Oct 10thfd, 2015, FOXGOLDEN begin to went into capital market and step into official listed company, stock code: 666153.
Thanks for 12-year customer support on FOXGOLDEN always.
Thanks for 12-year meterial supplier support on FOXGOLDEN always.
Thanks for 12-year FOXGOLDEN family constant effort and hard work.
We have 12-year production experience, We have 12-year design experience of offering solution, installation, and after-sales service, etc. According to different environment conditions, too cold temperature till -40℃ or too hot temperature till +55℃, we carefully choose different suitable materials and make the best offer for every customer. It differs in cables, LED lamps, plastic masks, waterproof materials, IC, etc. Faced with a variery of requirements, we offer flexible diverse solutions. We offer 24-hour all- direction online service.
As said by Jack Ma, the president of Alibaba group, it is the time of 3 wins. The meaning of FOXGOLDEN official website is WIN-WIN-WIN. WIN FOR CUSTOMERS; WIN FOR SUPPLIERS; WIN FOR FAMILIES. COM: COMING.
So means win-win-win, FOXGOLDEN has been coming to do it.
We are a young team, whose average age is 26.6 years old. Thanks, encourage, and effort always accompany us. Looking back to yesterday. We live Today, and will move towards better promising Tomorrow.
1.What is the difference between real pixel LED display and virtual pixel LED display ?
With the virtual pixel technology, the LED display will appear a more clear vision.
Theoretically the resolution will be 4 times of a real pixel technology LED display.
The difference of a real a virtual pixel LED screen of LED display can be seen in the next pictures.
2.How do virtual LED display work?
Below you can clearly see how the virtual pixels are made, we surely recommend you a virtual display, even so our new technology of Dot Matrix it’s still better than virtual pixels, because the three colors RGB are in the same dot or pixel, just like the SMD technology and also the Dot Matrix have a horizontal viewing angle of over 160 degrees. The virtual pixel LED display have a horizontal viewing angle of upto 130 degrees.
3. What is the refresh rate for LED screens?
The refresh rate of a LED display is the number of times in a second that the LED display hardware draws the data. This is distinct from the measure of frame rate in that the refresh rate for LED display includes the repeated drawing of identical frames, while frame rate measures how often a video source can feed an entire frame of new data to a display.For example, most movie projectors advance from one frame to the next one 24 times each second. But each frame is illuminated two or three times before the next frame is projected using a shutter in front of its lamp. As a result, the movie projector runs at 24 frames per second, but has a 48 or 72 Hz refresh rate.
4. Increase refresh rate for decreasing LED screen flickering
On LED display, increasing the refresh rate decreases flickering, thereby reducing eye strain. However, if a refresh rate is specified that is beyond what is recommended for the LED display, damage to the display can occur.
Normally our LED display have a refresh rate of over 300Hz, which is more than 5 times the refresh rate of a normal cathode television which is 50Hz (PAL and SECAM) or 60Hz (NTSC). For football stadiums (stadium LED display and perimeter LED display ) our LED display can reach a refresh rate of over 800Hz, which means that they won´t show any flickering when recorded with a video camera and broadcasted live on television.
---------------------------------
Email: info @foxgolden.com
Whats App: +86 15118019850
Welcome to contact us if you need more information or have any specialized inquiry. Thank you!!!
