Cat6a Patch Cord
- Ningbo or Shanghai
- T/T Money Gram
You May Like
Product Details
| Place of Origin | Zhejiang, China | Brand Name | LUCKTECH or OEM | |
| Model Number | LK-PC | Type | Cat 6a | |
| Number of Conductors | 4 |
Product Description
Specifications
1.Jacket:PVC/LSZH2.Insulation:PE
3.Conductor:BC CCS CCA
4,UL approved
SFTP Cat6A Patch Cord for network
Specification :
* 2×RJ45 plug molded version with strain relief and gold plated contacts.
* Meet EIA/TIA568
* Plug housing: PC (UL94V-0)
* Use life: at least 1000 times
* Insulation resistance: above 100MΩ
* Contact resistance: above10MΩ
* Length: 0.5m, 1m, 2m, 3m, 5m, 10m…….
Advantages :
1.Factory Manufacture with imdependent research and development ;
2.Competitive factory price ;
3.Certificated by ROHS / CE / ISO 9001 ;
4.Advanced production facility and perfect detection method ensure the excellent quality;
Applications :
1.Computer network cabling Project ;
2.Broadband Network Communication;
3.Digital ISDN Network and ATM 155Mbps Network
4.Ethernet Network ;
5.Audio and data transmission ;
SFTP CAT6 Patch cord
Conductor | Insulation | Core Number | Filler | Shielded | Braid | Jacket | ||||
AWG | Specification mm | Material | Thickness (NOM.mm) | Material | Thickness (NOM.mm) | OD (NOM.mm) | ||||
24 | 7/0.20 | HD-PE | 0.20 | 4P | PE Cross | AL/Mylar | TC or AL-MG | PVC or LSZH | 0.60 | 7.8 |
26 | 7/0.16 | HD-PE | 0.20 | 4P | PE Cross | AL/Mylar | TC or AL-MG | PVC or LSZH | 0.60 | 6.8 |
28 | 7/0.12 | HD-PE | 0.20 | 4P | PE Cross | AL/Mylar | TC or AL-MG | PVC or LSZH | 0.60 | 6.5 |
