This machine special for roll type t-shirt or plate garbage bag , others roll type bag and so on .
Standard or high speed
automatic punching auto roller
One line , two line
Available with Servo / Stepper Systems
High speed up to 200 strokes./min.
Micro processor based controller with digital display
Key pad setting for setting bag size and count.
Economical price
Double lay can improve the capacity
Two kind of use one is for plate bag ,another for vest bag
I |
Model |
TBE-500 |
1 |
Max length of bag |
20-1800mm |
2 |
Max width of bag |
50-450mm |
3 |
Thickness of film |
0.008-0.15mm |
4 |
Speed of line |
30-120 pcs/min one line |
5 |
Power |
6kw |
6 |
Main motor |
Controlled by inverter |
7 |
Weight |
1700kg |
8 |
Machinery Size |
3850x1300x1800mm |
II |
UNWIND |
|
9 |
Unwind line |
two line |
10 |
Driver Motor |
DC |
III |
SEALING AND CUTTING |
|
11 |
Sealing line |
one line |
12 |
Take up motor |
Setup motor |
13 |
Knife |
One |
14 |
Computer and operate board ,driver |
Each one set |
15 |
Punching type |
Hydraulic |
16 |
Punching mold |
One unit |
Market : Asia,middle east country , Africa and so on
Sales service :
supply material
Supply blow machine
For any type bag machine
Key parts description
No |
Key part |
Remark |
1 |
Control |
PLC or manual |
2 |
Punching |
With or without |
3 |
Shape |
T-shirt type roll or only roll |
4 |
Material |
HDPE , LDPE ,LLDPE,PVC,PP |
5 |
Sealing and cutting type |
Hot sealing and cold cut |
6 |
Speed and length control |
Automatic set and control by step motor |
7 |
Bag color |
With or without picture |
