CNC Vertical Machining Center

Name: CNC Vertical Machining Center
Brand: TZHISING
SKU: 122081909
Availability: InStock

US$ 45,000 - 49,000 MOQ: 1 Set

Key Specifications

Condition:

New

Type:

Vertical

Place of Origin:

Shandong, China

Tengzhou Hising Machine Tools Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao/Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Type Vertical

Place of Origin Shandong, China

Brand Name TZHISING

Model Number XK(H850)/XK(H)1050

Voltage 6kgf/cm2

Power(W) 7500

Dimension(L*W*H) 2800*2700*2560

Weight 4500kg

Certification ISO CE

Warranty 12 Months

After-sales Service Provided Engineers available to service machinery overseas

The Specification of the CNC Milling Machine or Vertical Machining Center

(XK(H)850/XK(H)1050):

Specifications	XH850	XH1050
Table size	460×950mm	460×950mm
Longitudinal travel	800mm	1000mm
Cross travel	500mm	500mm
Vertical travel	500mm	500mm
Spindle motor	7.5kw	7.5kw
Spindle speed	100-8000r/min	100-8000r/min
Spindle taper	BT40	BT40
Spindle nose to table surface	150-650mm	150-650mm
Spindle center to column surface	550mm	550mm
ATC type	Armless type Arm type
Magazine capacity	BT40/16Pcs BT40/24Pcs
Max. tool diameter	80mm 80 mm
Max. tool length	300mm 300 mm
Max. tool weight	7.5kg 7.5 kg
Tool change time	7sec 2.5sec
Electric power	10KVA	10KVA
Air pressure required	6kgf/cm	6kgf/cm
Positioning accuracy	0.015mm	0.015mm
Repeatability	0.01mm	0.01mm
Net weight	4500kg	4800kg
Machine weight(N.W/G.W)	2800×2700×2560mm	2800×2700×2560mm
