TF30A-D Diaphragm dc mini 6v 12v 24v Liquid pump
| Specification |
| Brand name | TOPSFLO | ||||||
| Model | TF30A-C | ||||||
| Motor | Coreless Brushless motor | ||||||
| Total life span | Above 15,000 hours | ||||||
| Pump head | Nylon | ||||||
| Diaphragm | EPDM / PTFE | ||||||
| Valve | EPDM / PTFE | ||||||
| Sealing fin | NBR | ||||||
| Voltage (DCV) | 6V | 12V | 24V | ||||
| Current (A) | 0.4 | 0.24 | 0.15 | ||||
| Flowrate (L/min) | 0.4 | 0.4 | 0.4 | ||||
| Max water head (M) | ≥10 | ≥10 | ≥10 | ||||
| Max vacuum (Kpa) | -70 | -70 | -70 | ||||
| Low Noise (dB) | <50 | <50 | <50 | ||||
| Light weight | 0.25kg | ||||||
| Pump size | L * W * H: 80 * 30.5 * 58mm | ||||||
| Product Feature |
1. Oilless, environmental protection media, can be used in the food industry
2 .Diaphragm liquid pumps have good self-priming function
3. Can run dry, there is no danger or damage
4. 24 hours continuous running is workable (will not stop working because of overheating)
5. Compact design
6. Can be made by PTFE (polytetrafluoroethylene) membrane, FPM valve (FKM), which are the good materials of anti-acid and alkali
7. Patented diaphragm structure, long maintenance-free life expectancy. ( if want to replace the diaphragm by your own, just need unscrew the head screws and do the replacement)
| Product Advantage |
1.Adopt enhanced importing dual bearings, which arevery wearable, can well match with 15,000 hours pump lifetime
2.Adopt metal balance cake, the the pump has good balance performance, very small vibration. (Domestic counterparts with plastic weights, has big vibration
3 With imported rubber diaphragm, high purity, good wear resistance. Besides, there is EPDM, PTFE valve, EPDM, FPM diaphragm optional, all these materials have better chemical resistance capability. .
4 The overall design & inner structure are the same as foreign famous KNF, Parker brands, the overall design is reasonable & compact, which assured TOPSLFO pumps’ high performance and low noise, low vibration and long lifetime.
| Packaging |
