12V DC Brushless quiet mini compact dc pump

1.  DC brushless motor with long lifetime more than 50,000 hours .

2. Low noise: ≤26dB, at 1 meter distance.

3. Heavy duty work, can sustain continual 24 hours.

4. Durable permanent magnetic rotor/impeller & fine ceramic shaft.

5. Advanced magnetic drive technology for static-impeller, without any leakage for ever.

6. Low or no maintenance.

7. Low power consumption.

8. Small footprint.

The similar quality and performance but more competitive price than DDC pump

Specifications	Topsflo TDC	Laing DDC	Picture
Operating voltage range:	6 to 13.2 VDC	8 to 13.2 VDC	Topsflo TDC-A
Rated power:	6 W	12 W
Max head:	0.8 ft (2.7 m)	7m
Nominal discharge :	400 LPH	8.7L/min
Maximum pressure:	58 Psi (4 Bar)	21.75 Psi
Temperature:	185° F(85°C)	140° F(60°C)
Size:	61.4*61.4*35.5mm	62*62*38mm	VS
Noise measurement:	26-30dBA	40dBA	Laing DDC
Weight:	200g	200g
Pump ideal life time:	50,000 Hours	50,000 Hours
RPM Signal:	single wire on 3 pin connector	single wire on 3 pin connector
Connection size:	3 / 8" barbs (10mm)	3 / 8" barbs (10mm)

Areas of Use:
Electronics ooling Laser Cooling Medical Water Circulation Chiller Systems Liquid Transfer General Purpose Pumping

FAQ



 More

What’s the main products of your company?

We specialized in all kinds of micro pumps (micro BLDC centrifugal water pump, micro gear pump, high performance diaphragm air/liquid pump) for over 10 years with excellent quality and competitive.

Please tell me your detailed flow rate, pressure, running time, voltage, application, fluid, ambient temperature and so on, then I will match the most appropriate pump for you, or you can choose the exact model in the product manual.

Our sales engineers can assist you with product selection and recommendation, troubleshooting and technical assistance, manuals and documentation, custom and unique product sourcing, complete application solutions and much more!

1.The stock samples can be sent to you within 3-5 days by international express after received

2.The batch order can be shipped to you in about 30-40days after order confirmation (by air or by sea)
