P10 Double Sided LED Display With 3000:1, Gray Level 14 Bits

Name: P10 Double Sided LED Display With 3000:1, Gray Level 14 Bits
Brand: IRIS
SKU: 121979367
Availability: InStock

US$ 27 - 997 MOQ: 1 Square Meter

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

IRIS

Model Number:

P10-NO309

IRIS Technology Co., Ltd.(Wuhan)

Payment & Shipping

Payment Methods:

Port of Shipment:

shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name IRIS

Model Number P10-NO309

Usage Outdoor

Tube Chip Color Full Color

Display Function Video

Pixels 10mm

Screen Dimension customized

P10 Double Sided LED Display with 3000:1, Gray Level 14 Bits

Product Description

Features:

1. High brightness. Use DIP LEDs, keeps the display content visible even if facing the strong sunshine directly.

2. With Anti-UV ray mask, the color of the mask would never change even if under exposure of UV ray.

3. Waterproof design, completely outdoor use.

4. Easy for assembling and connection with the connector added.

5. High color uniformity and clear image can bring you a vivid audio visual effect.

6. Both front and rear access are available.

7. Good LED Chips, with large viewing angle, lowe power consumption and good color uniformity.

8. Easy for maintenance.

9. Good quality raw material, accurate technique and careful inspection insures the high quality of led display.

10. Different shape and size can be made according to your requirement.

11. Items: P10, P12, P12.5, P16, P20, P25 etc.

12. Widely used for building, shopping mall, cinema, station, stadium, plaza, street etc.

Item	Parameter
Pixel	Physical pixel Pitch: 10mm
	Pixel Configuration: 1R1PG1PB
	Lamp	Wave
	R	618-628nm
	G	520+/-2.5nm
	B	470+/-2.5nm
Module	Size: 160×160 mm
	Resolution: 16×16 dots
Cabinet	Size: 640×640×150mm
	Physical Resolution: 64×64 dots
	Physical Density: 4096 dots
	Module Quantity: 16 pcs/Cabinet
	Material: Iron/AL
	Weight: 40kg (Iron)/30kg(AL)
	Average Power Consumption: 600W
	Max Power Consumption: 1000W
Electricity Parameter	Brightness:≥68,00cd/m2
	Physical Density:10,000dots/m2
	Whole Display Flatness:≤1mm juncture
	Best View Distance:≥10m
	Best View Angle: Horizontal: +/-120°Vertical: +/-50°
	Storage Temperature: -35+85; Working Temperature: -20+50
	Driving Method: Constant Driving Current
	Refresh Frequency: 300HZ
	Humidity(RH):≤90~95%
	Protection Grade: IP65
	Power Supply: AC 110V240V, 50/60HZ
	MTBF: 10,000hours
	Screen Lifetime: 100,000 hours
Control System	Control System: LCF Studio 2009
	Communication Distance: Internet cable:≤200m or Fiber cable: 1,000m or Wireless
