Help CenterPortable VMS Trailer With Video LED Display/Screen Full Color
Related Products
-
Digital Billboard Truck Mobile Led Display , Led Mobile Advertising Trucks for Sale, Mobile Led Screen TruckUS$ 27 - 997MOQ: 1 Square Meter -
China Supplier for 12V Red Car LED Programmable Message Sign Scrolling Display Board With Remote RedUS$ 27 - 997MOQ: 1 Square Meter
-
Hot Sale Large Mobile Food Trucks Outdoor P10 Led DisplayUS$ 27 - 997MOQ: 1 Square Meter
-
High Brightness P10 Mobile Led Display Screen Food Trucks for Sale in UsaUS$ 27 - 997MOQ: 1 Square Meter
-
Outdoor LED Mobile Advertising Mini Food Truck/advertising ScooterUS$ 27 - 997MOQ: 1 Square Meter
led display indoor/ led display modules/video outdoor dip led billboard p8 p10 advertising
Type Number |
PB.008.5000 |
PB.010.5007 |
PB.016.5002 |
PB.020.5001 |
PB.025.5000 |
Pixel Pitch(mm) |
8 |
10 |
16 |
20 |
25 |
LED standard |
DIP246 |
DIP346 |
DIP346 |
DIP546 |
DIP546 |
Pixel Composition |
1R*1G*1B |
1R*1G*1B |
1R*1G*1B |
2R*1G*1B |
2R*1G*1B |
Pixel density(dot/m2) |
15625 |
10000 |
3906 |
2500 |
1600 |
Module Dimensions(mm) |
256*128 |
320*160 |
256*256 |
320*160 |
200*200 |
Module resolution (L*W) |
32*16 |
32*16 |
16*16 |
16*8 |
8*8 |
Scan mode |
1/8 |
1/4 |
Static |
Static |
Static |
Brightness |
6500 |
7500 |
3200 |
6500 |
5500 |
Min.viewing distance (m) |
8 |
10 |
16 |
20 |
25 |
Cabinet size(L*W*H)(mm) |
1024*1024*170 |
960*960*170 |
1024*1024*170 |
960*960*170 |
1000*1000*170 |
Cabinet material |
Iron |
Iron |
Iron |
Iron |
Iron |
Cabinet weight |
45KG |
45KG |
35KG |
40KG |
45KG |
Power consumptionW/m2 |
Max.700 Average.350 |
Max.800 Average.400 |
Max.400 Average.200 |
Max.750 Average.400 |
Max.480 Average.250 |
Protection level |
IP 65 |
||||
View angle |
Horizontal 120 degree,Vertical 60 degree |
||||
Grey level |
4096 level |
||||
Working temperature |
-45~50°C |
||||
Life span |
≥30,000 hours |
||||
Working voltage |
AC220V/(110V)±15%,47~63HZ |
||||
Signal transfer |
LAN cable |
||||
Control system |
LED FLASH Computer control system |
||||
Production Process & Production Testing
our company and certification
IRIS Technology Co.,Ltd was found in early 2007 . IRIS committed to the next generation of LED optoelectronic products development, production, sales and service. It is leading the trend of LED industry and providing a full range of solutions to its customers. It has become a modern, large scale, professional LED Photoelectric comprehensive product integration supplier. The products sell well in over 50 countries and regions in Europe, America and Middle East, besides more than 20 provinces across China.
Our core value is to create the maximum value for our customers. So we design novel and creative products for the market.
1. IRIS is a professional LED display solution offer, designer & manufacturer founded by 8 key engineers of LED display industry.
2. Our seles tracking your order all the time, provide photos and videos for you.
3. Professional QC team: Double module/display aging time, vibration test, waterproof test, high & low temperature test and so on.
4. Technology training on the web or in the factory.
5. CAD drawing file for your projects and other expert suggestion.
6. What we supply is not only highly reliable products, but more professional Solutions & extended Services.
7. We have 4 engineers who have been working in LED display industry for over 12 years.
8. We are good at customized, complicated and integrated systems.
9. Our 15 experienced engineers are waiting for supporting you.
10. We have already done over 1000 projects all around the world.
