HD P3 SMD indoor RGB super slim aluminum led cabinet / 512mmX512mm / P4 indoor led display
| Item | Techinical Specifications | |||||
| Pixel Pitch | PH3.9mm | PH4.8mm | PH5.68mm | PH5.95mm | PH6.25mm | PH8.928mm |
| LED Configuration | SMD2121 | SMD2121 | SMD3528 | SMD3528 | SMD3528 | SMD3528 |
| Pixel Density | 65536pixels/m2 | 43264pixels/m2 | 30976pixels/m2 | 28224pixels/m2 | 25600pixels/m2 | 12546pixels/m2 |
| Module Size | 250*250mm | 250*250mm | 250*250mm | 250*250mm | 250*250mm | 250*250mm |
| Module Resilution | 64*64pixels | 52*52pixels | 44*44pixels | 42*42pixels | 40*40pixels | 28*28pixels |
| Cabinet Size | 500mm*500mm | |||||
| Cabinet Resolution | 128pixels*128pixels | 104pixels*104pixels | 88pixels*88pixels | 84pixels*84pixels | 80pixels*80pixels | 56pixels*56pixels |
| Cabinet Material | Die-casting Aluminum | |||||
| Cabinet weight | 8kg/pcs | |||||
| Brightness | 2000cd/m2 | 2000cd/m2 | 1800cd/m2 | 1800cd/m2 | 1500cd/m2 | 1500cd/m2 |
| Viewing Angle | H:140°/V:140° | H:140°/V:140° | H:140°/V:140° | H:140°/V:140° | H:140°/V:140° | H:140°/V:140° |
| Input Voltage | AC220V/110V,50HZ/60HZ (±10%) | |||||
| Output Voltage | 5V,40A | |||||
| Best Viewing Distance | ≥4m | ≥5m | ≥6m | ≥6m | ≥6m | ≥8m |
| Refresh rate | 2000Hz | |||||
| Grey scale levels | R(256bit) x G(256bit) x B(256bit) | |||||
| Display Colors | R(1024) x G(1024) x B(1024) | |||||
| Life-span | 100,000 hours | |||||
| Working Temperature | -20~+50℃/10~90%RH | |||||
| Malfunction dot rate | < 0.0001 | |||||
| Drive Mode | 1/16 scan | 1/13 scan | 1/11 scan | 1/7 scan | 1/10 scan | 1/7 scan |
| Ave Power consumption | 130W/pcs | 125W/pcs | 120W/pcs | 110W/pcs | 100W/pcs | 80W/pcs |
| Max Power consumption | 260W/pcs | 250W/sqm | 240W/sqm | 220W/sqm | 200W/sqm | 160W/sqm |
You may also like the following products
|
RGB outdoor P16 led advertising screen
|
Indoor usage indoor P6 LED display
|
New stage background activity P4 led screens
|
Production Process & Production Testing
our company and certification
IRIS Technology Co.,Ltd was found in early 2007 . IRIS committed to the next generation of LED optoelectronic products development, production, sales and service. It is leading the trend of LED industry and providing a full range of solutions to its customers. It has become a modern, large scale, professional LED Photoelectric comprehensive product integration supplier. The products sell well in over 50 countries and regions in Europe, America and Middle East, besides more than 20 provinces across China.
Our core value is to create the maximum value for our customers. So we design novel and creative products for the market.
1. IRIS is a professional LED display solution offer, designer & manufacturer founded by 8 key engineers of LED display industry.
2. Our seles tracking your order all the time, provide photos and videos for you.
3. Professional QC team: Double module/display aging time, vibration test, waterproof test, high & low temperature test and so on.
4. Technology training on the web or in the factory.
5. CAD drawing file for your projects and other expert suggestion.
6. What we supply is not only highly reliable products, but more professional Solutions & extended Services.
7. We have 4 engineers who have been working in LED display industry for over 12 years.
8. We are good at customized, complicated and integrated systems.
9. Our 15 experienced engineers are waiting for supporting you.
10. We have already done over 1000 projects all around the world.
