Help CenterCNC Metal Cnc Plasma Cutting Machine 1200x900
Related Products
Plasma Metal Cutting Machine
Features of plasma metal cutting machine
1.Computer -controlled and precision mechanical transmission
2.Good user interface makes the operation more convenient and simple,fast and accurately.
3.Compact structure, good rigidity and stable performance.
4.Applies the longitudinal bilateral synchronous drive system.
Features of plasma metal cutting machine
1.Computer -controlled and precision mechanical transmission
2.Good user interface makes the operation more convenient and simple,fast and accurately.
3.Compact structure, good rigidity and stable performance.
4.Applies the longitudinal bilateral synchronous drive system.
Technical Parameters:
Model |
CPC-1290-Metal Plasma Cutter |
Work area |
1200*900mm |
Cutting thickness |
1-10mm(Plasma power 65 included) |
Optional plasma power |
45A 1-6mm, 85A 1-16mm, 100A1-19mm |
Plasma power source |
American Hypertherm |
voltage |
3-phase 380V |
Power |
8.5KW |
Power frequency |
50HZ |
Drive type |
Step driver |
Files transfer |
USB Interface |
Transmission method |
Square rail/rack gear |
Picture format supported |
DXF/PLT,AutoCAD,UCANCAMV9 International standard code |
Work mode |
Untouched arc striking |
Adjustable high mode |
automatic arc voltage/mechanical adjustment |
Control mode |
CNC |
Cutting air source |
Compressed air |
Cooling method |
Air cooling |
Smoke exhaust system |
Rear exhausting smoke |
Processing materials |
Cold rolled plate, stainless steel, galvanized version, copper, aluminum and other metal sheet |
Net weight (kg) |
400kg |
Machine size (mm) |
2640*1740*1440 |
Gross weight (kg) |
600 |
Machine size (mm) |
2740*1840*1550 |
Note:No further notification is performed when the parameters and models are changed .
