Help CenterCNC Plasma Metal Cutting Machine
Related Products
Feature:
1. Plasma power: imported america-Haibao, size can choose, 380 V input.
2. Support for AI, DXF, PLT, and other graphic data format, accept MasterCam, Type3, wen tai software such as the generation of international standard G code
3. The numerical control system used at present advanced integrated module control method, ensure the equipment in high precision, high stability under the condition of reliable operation.
4. Automatic calculation of cutting cut on compensation, reducing the processing data production time, ensure machining graphics precise size.
5. Unique breakpoints, power off handling, processing process can track along the forward, back, flexible processing process of broken meet arc, power.
6. A graphic image data system, for publishing editor (such as scaling, rotating, alignment, copying, combination, split, smooth operation, merge and so
7. An increase of both the front and back output and programming and processing function of pre-cut border area
8.Auto ignition , auto- adjusting system ( arc voltage ) , cutting steel with
rugged features automatically increased to ensure that the cutting torch and
the same distance from the plate , thus ensuring the quality of the cut .
9.Off-line anti-jamming ability.
10.Its environmental sink dust handling system
Technical Parameters:CPC-1290
Modle |
CPC-1290 |
Unit |
Work area |
1200*900 |
mm |
Max.cutting depth |
8 (Cold rolled plate) 3 (Stainless steel) |
mm
|
Plasma power |
65 |
A |
voltage |
3-phase 380 |
V |
Power |
8.5 |
KW |
Power frequency |
65 |
Hz |
Files Transfer |
USB Interface |
|
Arc |
Untouched arc striking |
|
Control Method |
CNC |
|
Processing materials |
Cold rolled plate, stainless steel , galvanized version , copper , aluminum and other metal sheet |
|
