Home > Manufacturing & Processing Machinery > Laser Equipment > Laser Engraving Machine > CO2 Laser Marking Machine With Water Cooling

CO2 Laser Marking Machine With Water Cooling

CO2 Laser Marking Machine With Water Cooling photo-1
Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Laser Type:
CO2
Engraving Area:
200*200mm
Payment & Shipping
Payment Methods:
Port of Shipment:
QINGDAO SHANGHAI TIANJIN WUHAN
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Laser Type CO2
Engraving Area 200*200mm
Engraving Speed ≤3000mm/s
CNC or Not Yes
Cooling Mode Water Cooling
Place of Origin Shandong, China
Brand Name ARTSIGN
Model Number GL200
Dimension(L*W*H) 1950*410*1110
Certification CE, ISO
After-sales Service Provided Overseas service center available

CO2 laser marking machine with water coolingTechnical parameters:

Model

GL160

DB160RF

Max. laser power

Co2 glass tube 40W ,60W,80W,100W,

130W,150W(optional)

Chinese made CO2 RF tube 25W/50W(optional);

Imported CO2 RF tube Coherent 30W/50W (optional)

Laser wave-length

10.6um

Laser repetition frequency

20KHz

Standard marking area

110*110mm/160*160mm(standard)  220*220/300*300/400*400//500*500mm(optional)

Up and down

Manual up and down 100-200mm optional

Marking depth

≤3mm

Marking speed

3000mm/s

Min line width

0.5mm

Min character size

1mm

Repetition accuracy

±0.01mm

Power consumed

<1200W

Supply voltage

AC220/100V±10% 50/60Hz

Cooling method

Water cooled

Air cooled

Software system

Win XP/7/8 32/64bits + EZCAD marker system

Operating temperature

0-30℃

Net weight(kg)

75

Machine size(mm)

1950*410*1110

Gross weight(kg)

150

Packing size(mm)

2040*540*1250

 CO2 laser marking machine with water cooling
