Artsign Economical Laser Engraver
Technical Parameters:
Model |
JSM6045 |
Work area (mm) |
600*450mm |
Laser tube power |
35W/40W/60W |
Engraving speed |
1000mm/s |
Cutting speed |
400mm/s |
Engraving depth of acrylic |
1.5mm |
Cutting depth of acrylic |
35W max 8mm, 40W max 10mm, 60W max 20mm |
Communication interface |
USB |
Work table |
Passthrough, Honey comb board, Electronic up and down 170mm |
Minimum forming character |
1*1mm |
Maximum scanning precision |
0.0254mm |
Positioning precision |
0.01mm |
Power supply |
220V (or 110V) +/-10% 50Hz (or 60Hz) |
Drive mode |
Step motor |
Software included |
Lasercut |
Design software |
Coreldraw (compatible); Autocad, Photoshop |
Picture format supported |
PLT, DXF, BMP, AI (direct); JPG, GIF, PGN, TIF (conversion) |
Operation system |
Windows 2000/XP/VISTA/7/8 32/64bits |
Engrave curve surface |
Less than 1.5mm |
Cooler |
Water pump included / Water chiller optional |
Life time of laser tube |
1000-1500 hours (30/40W) 3000-4000 hours (60W) |
Certificate |
CE, FDA |
Net weight (kg) |
80 |
Gross weight (kg) |
120 |
Machine size (mm) |
980 x 750 x 450 |
Packing size (mm) |
1100 x 820 x 670mm (Wooden box) |
|
Accessories: 1.Exhaust fan and tube 2.Power cable 3.Water pump 4.Operation VCD 5.Keys 6.Caution label 7.Self-adhesive paper for adjusting the light path 8.Honey comb board 9.Focus ruler 10.Air pump with air hose and dia6mm air mouth 11.Knob for up and down work table | |
|
Optional: 1.water chiller optional, 2.chuck rotary, champagne rotary, adjustable angle rotary, mini chuck rotary optinal, 3.TL30W optional, EFR60W optional, EFR-ZN80W tube optional(frame enlarged), 4.hybrid stepper motor optional for 1500-2000mm/s high speed(frame enlarged) 5.Cabinet or stand leg optional 6.Passthrough 100mm optional(frame enlarged) | |
|
Consumable parts (Recommended): 1.Extra laser tube (30W,70CM or 40W,1M) 2.Extra 1 lens and 3 mirrors (Lens D18mm, F50.8mm. Mirror D20mm) | |
