H80 MINI CNC Horizontal Machining Center

Name: H80 MINI CNC Horizontal Machining Center
Brand: HANKUI
SKU: 121924341
Availability: InStock

US$ 151,564 - 170,123 MOQ: 1 Set

Key Specifications

Condition:

New

Type:

Horizontal

Place of Origin:

Shandong, China

Jinan Hankui International Trade Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Type Horizontal

Place of Origin Shandong, China

Brand Name HANKUI

Model Number H80

Voltage Customer's Requirement

Power(W) 15~37KW

Dimension(L*W*H) 3875x3380x3700 mm

Weight 13000kg

Certification ISO CE

Warranty 12 Months

After-sales Service Provided Engineers available to service machinery overseas

Product Description

Export Products

H80 MINI CNC Horizontal Machining Center

1.The whole lathe bed, column, workbench, wagen, spindle box and other big parts are all of

high quality resin sand molding and high strength cast iron, which make the precision of lathe

with high rigidity and long term stability. The interior of lathe is decorated with the triangular

stiffener, which can make the lathe bed more stable, so that can make the precision of lathe

with high rigidity and stability for a long time

2.The heavy duty roller guide which made in Taiwan has strong rigidity, and good dynamic

performance. The imported screw which has large diameter is cooperated with the international

advantage lead screw auxiliary support system . It is of compact structure, smooth movement,

and high accuracy. So the machine driven system is of high rigidity and high stability.

Product-related Data

Item		H80	H80/1
worktable	Worktable size	800×800mm	800×800mm
	Worktable quantity	1	2
	Indexing unit	1°X360	1°X360
	Max. load	1500kg	1500kg
	Max. workpiece swing dia.	1600mm	1600mm
Travel(Reverse T type structure)	X axis travel	1300mm	1300mm
	Y axis Headstock travel	1000mm	1000mm
	Z axis column travel	1000mm	1000mm
Spindle BT50	speed	6000rpm	6000rpm
	Spindle center line to table surface	120~1120mm	0~1000mm
	Distance between spindle nose to table center	200~1200mm	200~1200mm
Rapid speed	X, Y, Z axis	36m/min	36m/min
	B axis	10r/min	10r/min
Positioning accuracy	X, Y, Z axis	0.012	0.012
	B axis	12″	12″
Repositioning accuracy	X, Y, Z axis	0.008	0.008
	B axis	6″	6″
Controller FANUC(standard), SIEMENS Mitsubishi KND(optional)	X axis servo motor	30N.m	30N.m
	Y axis servo motor	30N.m	30N.m
	Z axis servo motor	30N.m	30N.m
	B axis servo motor	12N.m	12N.m
	Spindle servo motor	15~37KW	15~37KW
	APC servo motor		22N.m
Dimension		3875×3380×3700	5780×3380×3700
G.W		13000kg	16500kg
