Auto Bending machine
Feature:
² Automatic feed,automatic notch,automatic bend(min diameter of bend is 15MM).Automatically cut any angle from 35°to 135°.
² No need to fit the trimcap separately,simplify the fabrication progress.
² High speed,using the actrating-moto to control machine,it only takes 48 seconds to finish one 30cm letter like “s”.
² Available material width ranges from 30mm to 128mm.
² Energy saving and environmental protection,total power 700W,actual service power less than 700W.
² Can read muti-vector file like the formeat such as:dxf,ai,matching with the engraving file.
² Size:2350*850*1750mm Processing materials:stainless steel/iron/aluminium alloy Processing width:30mm-128mm Stainless steel304# less than or equal 0.8mm iron,aluminium:0.4mm-1.2mm.
² Special specification and requirement is available.
Technical Parameter:
Model |
WZ03 |
voltage |
220V,50HZ |
Power |
3KW |
Air pressure |
0.6Mpa |
Accuracy |
±0.05mm |
Drive mode |
Step drive |
Net weight(kg) |
200 |
Machine Size(mm) |
2080x850x1660 |
Gross weight(kg) |
275 |
Packing Size(mm) |
2180*950*1810 |
