Specifications
GS12 Plastic Bottle Blow Molding Machine is especially used to produce 3 gallons and 5 gallons PET bottlesTrait:
Plastic Bottle Blow Molding Machine GS12 is especially used to produce 3 gallon and 5 gallon bottles and is widely used to produce any shape of plastic from PET with neck finishes from 15mm-200mm. Perfect function with economic investment. Small size and compact construction with no space waste. Easy to operate and maintain ,operation by one person . Saving power and uneasy to worn out ,Adopting new double crank four bars to lock mould, the cross fixed. Providing high pressure blowing system. We can provide performs and various bottle& cap molds for 5 gallon and 3gallon bottles to meet customers requirements.
Technique Parameter of blow molding machine:
Main parameter: | ||
Model |
GS12 |
|
Container |
Product material |
PET |
Volume |
10L-25L3-5Gallon |
|
Theoretical output |
90-180PCS/H |
|
Perform length |
15mm-460mm |
|
Perform inner diameter |
φ5mm-200mm |
|
Molding |
Max. mould plate Dimension(L x W) |
420x500mm |
Max. mould thickness |
40mm |
|
Clamping force |
330KN |
|
Mould opening stroke |
38mm |
|
Machine size and weight |
Main machine (L x W x H) |
218*77*196cm |
Main machine weight |
1000Kg |
|
Heater (L x W x H) |
237*68*165cm |
|
Heater weight |
380Kg |
|
Power |
40kw |
|
