high quality full color xxx china indoor led display xxx pic for P4
- 1000 Square Mile / Square Miles per Month
- shanghai port for high quality full color xxx china indoor led display xxx pic for P4
- T/T L/C D/P D/A Credit Card PayPal
- 60W UL CE LED Canopy Lamp with aluminum frame Ex-factory price from Shenzhen
- 80W Energy-Saving Gas Station LED Canopy Lamp hot sale from Shenzhen
- 60W UL CE Energy Saving LED Canopy Lamp with 3 years warranty from Shenzhen
- 2014 new design, led flood light, led Gas Station Lamp, LED canopy light 100w
- Led flood light, led Gas Station Lamp, LED canopy light 100w
- 120W High power cree led canopy lamp Wholesale from Shenzhen for gas staton
Product Details
Place of Origin: | Shanghai, China | Brand Name: | Harse led display | Model Number: | led display screen |
Usage: | Outdoor | Tube Chip Color: | Full Color | Display Function: | Video |
Pixels: | Other, indoor led display, 10mm indoor led display | Screen Dimension: | Custom indoor led display |
Product Description
high quality full color xxx china indoor led display xxx pic for P4
Features of Rental super led display screen :
> Slim and light
> Easy to install design
> Multi input and specially software
> Impact resistance
> Support different solutions of Rental super led display screen
> Specially suitable for broadcast
> Portable and easy transport
> Adjustable view angle of Rental super led display screen
> Soft Ware: Windows Base & User Friendly Easy Installation
> Manual & Automatic Control via Network Wireless, Fiber, & Telephone
> All Common Video Format Support : WMV , MPEG , AVI , SWF , ASF ,
DVD , VCD , RF , HTML , SVIDEO , RGB , YUV , YC , . . .
Rental super led display screen Introduction:
Item | led display Technical Specification |
Pixel | Pixel pitch: 4mm |
Pixel configuration: 1R1G1B | |
Brightness: Red: 1000mcd Green: 2300mcd Blue: 600mcd | |
Wave length: Red: 625±2nm Green: 525±2nm Blue: 470±2nm | |
Module resolution: 64×32 pixels | |
Module | Module size: 256mmx128mm |
Cabinet size: 512mm×512mm×70mm | |
Cabinet | Cabinet resolution: 16384 pixels |
Cabinet material: Steel | |
Gross weight: 30kg | |
Module quantity: 36 pcs= 2(w) 4 6(h) | |
Power consumption : Max.:760W/m² Average: 400W/m² | |
Screen parameter | Drive method: 1/16 Constant Current |
Brightness: 7000cd/m² | |
IC driver: MBI 5024GF | |
Density: 62500 pixel/m² | |
Whole display flatness: ≤ 1mm juncture | |
Best view distance: ≥ 4m | |
Viewing angle: Horizontal: 140° Vertical: 120° | |
Humidity(RH): ≤ 10~95% | |
Working temperature: from -30°C~ +60°C | |
Working voltage: AC220V/110V±20% | |
Refresh frequency: 2400Hz(Zdec) ≥ 300Hz(Linsn) | |
Frame rate: ≥ 540Hz | |
Protection grade: IP43 | |
MTBF: More than 10000hrs | |
Life time: 100,000 hrs | |
Control system | Control system: Linsn |
Signal interface: DVI/LAN | |
Communication distance: Internet cable: ≤120m / Fiber cable: 1000m | |
Systems operating platforms : XP,WINDOWS(WIN95,WIN98,WIN2000) |
Application of Rental super led display screen:
Aluminum rental cabinets for rental super led display screen
Packing information of Rental super led display screen
Certification of Rental super led display screen
Factory production line of rental super led display screen
Warranty of rental super led display screen : led screen display
1.We guarantee all our display, modules, spare parts (Silan Chip) for TWO years.
2.We provide technology training for free, which contains the operation and maintenance training of the LED screens in the factory.
3.After warranty , we also can offer you the parts for replacement at our bottom price.
4.After sales, if you have any problem about our product, you can inform us by Email, we will reply you at once when we get it and offer you a good solution to solve the problem.
5.We also could solve problems for you until it recovers well by remote control!
Delivery Time of rental super led display screen:
1.Delivery time: Accomplish manufacturing within 2~3 weeks after receiving the deposit.
2.Before delivery, we will test the display, and keep it light up for 72 hours, and check all the parts of the display to confirm it is Ok for delivery.
Installation of rental super led display screen:
1.We can assist the training and technical support for the customer in the factory, if the customer requires so.
2.We could send our engineer to guide the installation for you. But the relevant cost should be paid by your esteemed company.
3.Our technicians will offer CAD Drawing to show how to install the LED Display rightly and fast, of course, if you need.
A. What is LED?
LED is the abbreviation leds (LIGHT EMITTING DIODE), it’s emit visible wavelengths led in the led video display industry
B. what is a pixel and pixel pitch?
The pixel is the smallest unit of light-emitting, consists of red, green and blue colors. The same as ordinary computer monitors.
Pixel pitch refers to the center of the distance between two adjacent pixels.
C. what is the DIP, SMT and SMD?
DIP is DOUBLE IN - LINE PACKAGE, dual-in-line assembly
SMT is FACE SURFACE MOUNTED technology, Is currently one of the most popular technology in the electronic assembly industry;
SMD is SURFACE MOUNTED DEVICE.
D. what is the LED display module?
The base unit determined by circuit and installation structu re, has the display function, can simple assembling.
E. What is 3 in 1? What is its advantages and disadvantages?
is the RGB color of LED chips encapsulation SMT light vertical tied together according to certain spacing.
The advantages are: simple production, display effect is good,
The disadvantage is spectral color separation difficult, high cost;
