COL7105T H.264 HD STB-T / Dvb t Mpeg4 Set Top Boxes

COL7105T H.264 HD STB-T / Dvb t Mpeg4 Set Top Boxes thumbnail-1
COL7105T H.264 HD STB-T / Dvb t Mpeg4 Set Top Boxes photo-1
Negotiable MOQ: 1000 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Sichuan, China
Brand Name:
COLABLE
Model Number:
DVB-T
Contact Supplier Request Quote Chat Now
Colable Electronics Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Sichuan, China
Brand Name COLABLE
Model Number DVB-T

Specifications

1.dvb t set top box
2.Multi condition receiving systerm
3.Power-off memory, LED display, one key return
4. hd digital set top

H.264 HD STB-T dvb t





Features:

²  MPEG2/H.264/AVS Decoding

²  Compound Audio and video output

²  RS-232 interface for software upgrade

²  Support software upgrading online and USB upgrading

²  Memory function for power off

²  PAL/NTSC auto identify

²  Embed several game

²  Support NVOD

²  Support Mosaic program

²  Support playing USB electronic photo or picture and slide

²  PVR record

²  Support single/double network

²  Support CAS e-mail, OSD

²  Support data broadcasting system

²  Support picture show when power on device and can upgrade the picture if needed

²  Support EPG

²  The max rate for distinguish rate to showing rate is  1920x1080x60p







Specification



item

specification

CPU

RTD2882Q

STi7105

Central frequency

270MHz

450MHz

Flash memory (MByte)

8

16MByte(SPI)+1GByte(NAND)

SDRAM/DDR/DDR2 (Mbit)

512 DDR

1G DDR2x2

demodulation

DC2000

TDM5510





Work frequency

110~862MHz

Input resistance

75Ω

Input level

Min signal level(64QAM)≤34dBuv

Max signal level(64QAM)≥100dBuv

demodulation

≤24dB(64QAM,6.875Mbaud)

symbol rate

1~6.952MS/S

Noise value

Typical:6dB,Max: 9dB

CH bandwidth

8MHz

Demodulation mode

Based on DVB-C 16/32/64/128/256QAM









Input output interface

Rf input

Imperial F

Rf loop output

IN-IEC 169-1 male

Video

1 rute compound video

Stereo audio output

2 rute audio

HD output

1 HDMI1.3( with HDCP),1 progressive scan

fiber interface

1  S/PDIF

S-VIDEO output

1   S

USB interface

1  USB 2.0(1 option at front panel)

RS232

1  DB-9 female

LED

4 digital with 7-section , support time showing



video decode

HD:H.264/VC-1/MPEG2

SD: H.264/VC-1/MPEG2/AVS

Audio decode

Support MPEG 1, 2, MP 3, DD/DD+, AAC/AAC+, and

WMA9/WMA9pro

Distinguish rate, display rate

HD max:1920x1080x60p

SD max: 720 x480 or 720x576,

Support 4:3 and 16:9
