HJG Stopper Caps Drying and Sterilization Oven

HJG Stopper Caps Drying and Sterilization Oven photo-1
US$ 5,000 - 10,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Shanghai, China
Brand Name:
DEVELOP
Model Number:
HJG
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Shanghai, China
Brand Name DEVELOP
Model Number HJG
Type Other

Specifications

stopper caps drying and sterilization oven

HJG  stopper/caps drying and sterilization oven







I.                               Technical parameter:

1.      Overall size: 1450×1000×1400mm

2.      Drum size: Φ600×600mm

3.      Heating power: 9KW

4.      Working noise: ≤62 dBs

5.      Temperature range: 30 to 350°C

6.      Filtering class: ≥99.95%

II.                             Structure character:

HJG high effiency stopper/caps drying and sterilization oven are continuously rotating when drying. This equipment are made of body, blowing system, water cooling system, temperature self control system, rotate body, and exhaust air system. Main material of machine is SUS304, and this machine are install with class 100 laminar flow filtering device which can get to need of GMP. The equipment can be widely applied in washing stopper, Al caps, AL/PVC caps  etc.

III. Main component list of machine



Item

Qty

Specification

Brand

Tank Body

1set

Circular arc welding and polishing

ZHANGJIAGANG PUXINAG

Cycle fan

1unit

1.5KW

NANGJING CHENGGUAN

Entrance fan

1unit

0.55KW

JIANGSU DAZHONG

Wet discharging fan

1 unit

0.55KW

JIANGSU DAZHONG

High temperature high effiency fileter

1Piece

Contacted with cold fan

CHANGZHOU GUOYI

High temperature high effiency fileter

1Piece

Contacted with wet discharge fan

CHANGZHOU GUOYI

High temperature high effiency fileter

1unit

Contacted with air flow device of cleaning room

CHANGZHOU GUOYI

Solenoid valve

1piece

1/2 ”(ZCT-10)

SHANGHAI QIDONG

Water cooling pipes

1set

Φ22

WUXI TEGANG

Stainless steel heating pipes

9pieces

1KW/piece

SHANGHAI JIARE

Temperature control meter

1unit

ND-6000

SHANGHAI YATAI

Temperature sensor

1piece

PT100

SHANGHAI

Other electric components





DELIXI

Heat insulating material



aluminosilicate refractory fibers

SHANGHAI QIANGLI
