Home > Manufacturing & Processing Machinery > Pharmaceutical Equipment & Machinery > Pharmaceutical Tablet Equipment > ZP680C High Speed Three Layer Tablet Press Machine

ZP680C High Speed Three Layer Tablet Press Machine

Name: ZP680C High Speed Three Layer Tablet Press Machine
Brand: DEVELOP-MC
SKU: 121849355
Availability: InStock

ZP680C High Speed Three Layer Tablet Press Machine thumbnail-1

ZP680C High Speed Three Layer Tablet Press Machine photo-1

Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Condition:

New

Place of Origin:

Shanghai, China

Brand Name:

DEVELOP-MC

Contact Supplier Request Quote Chat Now

Shanghai Develop Machinery Co., Limited

Payment & Shipping

Payment Methods:

Port of Shipment:

shanghai

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Place of Origin Shanghai, China

Brand Name DEVELOP-MC

Model Number ZP680A

Type Rotary Tablet Press

Production Capacity 328500pcs/h

Max. Pressure(KN) 150KN

Max. Tablet Thickness(mm) 8mm

Max. Tablet Diameter(mm) 50mm

Voltage 380V/3/50HZ or made to need

Power(W) 15KW

Weight 4000KG

Dimension(L*W*H) 1150*1150*1900

Certification CE

After-sales Service Provided Engineers available to service machinery overseas

Specifications

High Speed Tablet Press
CE certificate
SUS304
GMP standard
ISO9001 cetificate

ZP680A High Speed Three layer Tablet Press machine

Description:

This machine is a double-press type .continuous automatic tablet press for pressing granular raw materials into tablets .It is mainly used in pharmaceutical industry and also the chemical, food, electronic industries.
1. Produce all kinds of round tablets, irregular tablets, double-layered and annular tablets.
2. The outside part of the machine is fully-enclosed, The material of the cover and the inside table face is stainless steel .The turret face is specially disposed keeping the luster of the face and prevent the cross pollution, meeting the GMP requirement.
3. It has transparent windows so that press condition can be observed clearly and the window can be opened Cleaning and maintenance is easier.
4. The lay-out of all the controllers and the operate parts is reasonable.
5. The speed adjustment of the driver is controlled by the frequency conversion device.
6. All the drive devices are located inside the machine so keep the machine clean.
7. A overload protection unit is included in the system to avoid the damage of the punches and apparatus, when overload occurs, the machine stops automatically.

Model	ZP73C	ZP65C	ZP51C	ZP35C	ZP27C	ZP45C
Dies quantity: sets	73	65	51	35	27	45
Max working pressure KN	60	80	100	120	150	80
Punch shaft diameter mm	19	22	26	40	50	25.35 (D TOOL)
Middle Mould diameter mm	22	26	34	52	68	38.1 (DTOOL)
Max tablet diameter mm	11	12	22	40	50	20
Max filling depth mm	15	15	18	18	18	18
Max tablet thicknessmm	6	6	8	8	8	8
Turret speed r/min	25	25	20	15	10	20
Max output pc/h	328500	292500	183600	31500	16200	162000
Voltage	380V/50hz or 220v/3/60hz
Main motor power kw	7.5	7.5	11	15	15	7.5
Overall size mm	1150×1150×1900
Weight kg	3500	3500	3800	4000	4000	3800
