Help CenterArticulating Boom Lift
Related Products
Specifications
articulating boom liftGTZZ12
GTZZ15
GTZZ18
Articulating Boom Lift Features
n Auto-leveling platform, with plus-minus 180° rotation.
n 130° to 140° vertical movement of short boom, 180° horizontal movements of the short.
n Boom in rotating boom. Nearly access to the limit value of working range in theory.
n NO turntable tail swing.
n Narrow tread.
n Capable of crossing limited space.
n Intelligent proportion controller allows simultaneous multi-movem ents, with precise positioning
ability.
1. platform control station
1.1. Proportional control is employed for boom elevation, platform rotation
and traveling.
1.2. One independent joystick control travel speed and rotation
1.3. Both hands sim ultaneously control movements of travel, turret
rotation, boom elevation, telescoping without releasing the f oot
switch
1.4. Tilt alarm/indicator light.
1.5. Engine start/accelerator and travel speed selection.
1.6. Engine f ailure warning lamp (only with EUROIII engine, option),fuel
level warning lamp, tilt warning lamp, system failure lamp.
1.7. Emergency stop, emergency pump and alarm horn.
1.8. Steel console cover.
2. turret control station
2.1. Interchangeable switch for turret/platform control.
2.2. Boom elevation, telescoping and rotation.
2.3. Travel, steering and platf orm level adjustment.
2.4. Engine start / stop and accelerator.
2.5. Charge lamp, system failure lam p, fuel level warning lamp.
2.6. Hour meter.
2.7. High engine water outlet temp. Shut down / indicator lamp.
2.8. Low engine oil pressure shut down / indicator lamp.
2.9. Emergency stop, emergency pump.
2.10. Control console & main cpu (plvc).
2.11. Hydraulic oil level gauge.
3. Hydrostatic drive.
4. Drive alarm.
5. head & tail lights (option)
6. Flashing amber beacon.
7. Platform work light (option).
8. Boom wipers, anti-dirt cylinder bellows.
9. Rotation lock pin.
10. Emergency manual pump (option).
11. DC emergency pump.
12. Lifting/tie down lugs
13. Free wheel device
14. Air breather with filter are equipped in fuel/ hydraulic oil tank.
