Help CenterMIG-500 Welding Machine
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Fujian, China
Brand Name:
ZZwelder
Model Number:
MIG-500
Payment & Shipping
Payment Methods:
Port of Shipment:
Xiamen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
MIG-350 Good Quality Long Life Welding Machine (seperate)NegotiableMOQ: 1 Set -
MIG-160 Inverter Welding MachineNegotiableMOQ: 1 Set
-
MIG-500 SCR MIG Gas Welder With Separated Wire FeederNegotiableMOQ: 1 Set
-
MIG-200 Inverter CO2 Gas-shield Welding MachineNegotiableMOQ: 1 Set
-
MIG-160 Inverter CO2 Gas-shield WelderNegotiableMOQ: 1 Set
Place of Origin
Fujian, China
Brand Name
ZZwelder
Model Number
MIG-500
Wire Feeding Speed
3~15m/min
Dimensions
960*582*860
Weight
220KG
Usage
welding
Specifications
1.good welding capability, stable arc burning,2.reliable usage, convenient operation
3.mig welding machine manufacturer
This MIG welding machine is to use turning switch and change number of primary coil to accommodate welding voltage. It has several features of good welding capability, stable arc burning, reliable usage, convenient operation, and simple repair etc. it can do stitch welding, space welding and spot welding. It can also adopt semiautomatic consumable electrode that is protected by ArCO2or Ar +CO2 to weld metal that of ordinary steel,low alloy steel stainless steel aluminum copper etc.
♣Technical Parameter:
| Type | MIG-500 |
| Input Voltage | Three-phase 380V |
| Duty Cycle | 60/80/100% |
| Frequency | 50/60HZ |
| Range of Regulation Electrical Current | 16A/17V~56A/42V |
| Welding Source No-load Voltage | 19-55V |
| Wire Speed | 3-15M/min |
| Wire Reel | 270mm |
| Welding Wire(mm) | steel 1.0~1.6mm |
| stainless 1.0~1.6mm | |
| aluminum 1.2~1.6mm | |
| copper 1.2~1.6mm | |
| Pilot Voltage | 24V/AC |
| Isolated Rank | F |
| Protect Rank | IP21S |
| Weight (KG) | 220 |
| Size(L×W×H)mm | 960×582×860 |
Pass through CE certification.
Client's own logo will be accepted when the quantity is above 50pcs.
