SH series Horizontal Band Saw
Technical Specifications:
Model |
SH-2240 |
SH-2835 |
SH-2835A |
|
Cutting Capacity (mm) |
Round |
220 |
280 |
280 |
Rectangular |
400W x 100H |
350W x 250H |
350W x 250H |
|
|
Saw Blade (m/min) |
Speed |
21/34/43/60 |
27/40/54/68/80 |
20 -- 90 |
Size |
27×0.9×3045 |
27×0.9×3505 |
27×0.9×3505 |
|
Tension |
Manual |
Manual |
Manual |
|
|
Motor Power (kw) |
Main Motor |
1.5 (4P) |
2.2(4P) |
2.2(4P) |
Hydraulic |
--- |
0.75 |
0.75 |
|
Coolant Pump |
0.075 |
0.075 |
0.075 |
|
Feeding Method |
Manual |
Manual |
Automatic |
|
Workpiece Clamping |
Manual |
Hydraulic |
Hydraulic |
|
Worktable Height (mm) |
630 |
690 |
690 |
|
Machine Size (L×W×H) (mm) |
1600 x 610 x 1130 |
1800×1050×1400 |
2100 x 1800 x1400 |
|
Model |
SH-2830 |
SH-3535 |
|
Cutting Capacity (mm) |
Round |
280 |
350 |
Rectangular |
300W x 220H |
350W x220H |
|
|
Saw Blade (m/min) |
Speed |
20/45/75 |
20/45/75 |
Size |
27×0.9×3505 |
34×1.1×4115 |
|
Tension |
Manual |
Manual |
|
|
Motor Power (kw) |
Main Motor |
1.8 (4P) |
2.2(6P) |
Hydraulic |
0.37 |
0.75 |
|
Coolant Pump |
0.075 |
0.075 |
|
Feeding Method |
Manual |
Manual |
|
Workpiece Clamping |
Hydraulic |
Hydraulic |
|
Worktable Height (mm) |
590 |
635 |
|
Machine Size (L×W×H) (mm) |
1510 x 830 x 1200 |
1900×1060×1200 |
|
