Steel Barn Forming Machine

  Steel silo forming machine Goods description

  Rx4.0m/m Steel Belt Forming and Seaming Machine is produced by our company

in 2005,  which is the latest machinery for steel storage  (pool)  machine.  It is the

advanced national standard product based on foreign SM40 machinery, which has

the same function, easy to handle and repair, it can reduce assembling procedure

with different diameters, and save time of machine installation, in this case the costs

of construction is greatly reduced, and make the Rx4.0m/m Steel Belt Forming and

Seaming Machine of our company more competitive than the foreign SM40 machinery

  At present,the Rx4.0m/m Steel Belt Forming and Seaming Machine of our company

adoptshigh strength alloy steel structure, and greatly improves the service life of the

machinery. However, the price is only onefourth of the foreign SM40 machinery, we

warmly welcome all the customerscome to visit us and place orders.

MAIN TECHNICAL SPECIFICATION

Size:Forming machine:1500mm × 1200mm × 1500mm

         Curving machine:1500mm× 1200mm ×1000mm

Total Weight: about 3000kg

Press wheels:carbon steel,high-frequency quenching HRC48 - 52

Gears:carbon steel , high-frequency quenching HRC48 - 52.
Sprocket wheel: carbon steel , high-frequency quenching HRC48 - 52.

Thickness of the coil: max 3 mm

Suitable diameter: ≥4m

Electric Standard: 380V / 50 HZ / 3 PHASE

Raw material and thickness:

Galvanized steel: 2-4mm

Chromium-nickel steel: 2-3mm, anti-corrosive

Plastic-coated steel: 2-4mm

Carbon steel: 2-4mm

Width of raw material:495mm

Dia meter range of finished silo:2.5-50m

Height of finished silo: usually less than 30m

Feed speed: 3.5-4.5m/min

The steel silo ( pool wall) are widely used as:

1) Material shape (storage): granular material, powder material, liquid material.

2) Industry: grain, feedstuff, Brewing, oil, medicine, food, cement, water treatment,

    etc.

3) Varieties in detail (storage): wheat, soybean, maize, sorghum wheat flour,

bulk cement, fly ash, sewage, water, chemical syrup, etc.

4) Ordinary black steel sheets, galvanized steel sheets, nickeling steel sheets,

high strength steel sheets, stainless steel sheets, aluminum alloy sheets, sand

wich panels, plastic coated metal sheets. Among them, the steel sheets, galva

nized steel sheets, aluminum plate sheets, aluminum alloy sheets, chromium

plate sheets, nickeling steel sheets, sandwich panels can be curved in double

layers.

 In a word, these metal containers are widely used in our country. it can replace

 the traditional welding metal containers. So the excellent construction speed ,

reliable performance and quality assurances of Rx4.0m/m steel belt forming and

 seaming machine become the preferred choice of the investment professionals.

Another  Kind of Silo Machine

Galvanized Steel Silo Roll Forming Machine With 18 Forming Stations

I. Galvanized Steel Silo Roll Forming Machine With 18 Forming Stations -- Widely Used

1. Material shape (storage): granular material, powder material, liquid material.

2. Industry: grain, feedstuff, Brewing, medicine, food, cement, etc.

3.Varieties in detail (storage): wheat, soybean, maize, sorghum wheat flour, bulk cement, fly ash, sewage, water, chemical syrup, etc.

4. Ordinary black steel sheets, galvanized steel sheets,high strength steel sheets, stainless steel sheets, aluminum alloy sheets.

II. Galvanized Steel Silo Roll Forming Machine With 18 Forming Stations -- Configuration

10 Tons decoiler(manual or hydraulic) -- 1 unit

Roll forming machine -- 1 unit

Punching system -- 2 units

Cutting system -- 1 unit

PLC control -- 1 unit

Hydraulic station -- 1 unit

Runout table or 6M auto stacker -- 1 unit

Spare tools -- one box

III. Galvanized Steel Silo Roll Forming Machine With 18 Forming Stations -- Working Process

Decoiler (10T Manual or Hydraulic) -- Guided Feeding -- Leveling -- Roll Forming -- Punching -- Arching -- Cutting -- Collection Table

Galvanized Steel Silo Roll Forming Machine With 18 Forming Stations

IV. Galvanized Steel Silo Roll Forming Machine With 18 Forming Stations -- Main Parameters

Suitable Raw Material Galvanized sheet, Zinc aluminum sheet

Material’s Thickness 1.2-4.5mm

Forming Stations 18

Maximum Feeding Width 1250mm

Diameter of Roller’s Shaft 120mm

Producing Speed 4-8m/min

Material of Roller GCr15 quenching HRC 58-62°

Drive Mode Gear Box

Main Power about 180KW

Electrical Control System PLC Frequency Control

Dimension(L*W*H) 35m*4.5m*4.5m

Total Weight approx 70T

V. Galvanized Steel Silo Roll Forming Machine With 18 Forming Stations -- Popular ProfileGalvanized Steel Silo Roll Forming Machine With 18 Forming Stations

VI. Galvanized Steel Silo Roll Forming Machine With 18 Forming Stations -- Sample
