Specifications
ice maker machine1. High Quality
2. High Output
3. Energy Saving
4. Easy for Storage
Name: Automatic energy-saving ice maker machine
Ice maker machine:
1. Tube ice plant produces food grade ice. Tube ice is edible ice.
2. Tube ice plant you can see often in Restaurant, Hotel, and Wine bar and so on.
3. Tube ice machine for tube ice
-External diameter: 22mm, 28mm, 35mm and 42mm.
-Inner diameter: 5mm-10mm, can be adjusted according to ice making time
-Length: 25mm-42mm
The machine for tube ice features:
More thicker, transparent, nice appearance, long storage time, uneasy to melt, good air permeability.
Perfect design: adopt 3D simulation assembly, compact structure, easy operation.
Health: ice maker adopts SUS304, PE, and aluminium material to process, and adopts big rounded excessive design, everywhere of the machine is easy to clean.
Efficient performance: ice maker adopt special alloy material and with special heat treatment, make the ice maker with best thermal performance.
Full automatical: PLC system controls the whole ice making process
tube ice machine
Perfect companion for your drinking in each season
Mainly apply for human consumption such as freeze drinks ,mixing wines ,cooling food stuffs ,and also
used for chemical cooling ,food processing ,fisheries ,poultry -processing ,meat plants etc .Welcome
for catering with the speial large production range from 1000kg/24hrs to 80T/24hrs attract more and
more ice factories found to sell ice in packed bags to a number of restaurant in cities ,which seems
gradually become a global trend ,such as Argentina in Brazil ,Malysia ,Singapore ,Indonisia ,
South-Africa...
| Model/Parameters | IT1T-R4A | IT2T-R4A | IT3T-R4A | IT5T-R4A | IT10T-R4A | IT15T-R4A | IT20T-R4A |
| Ice productincapacity (kg/24hour) | 1t/24h | 2t/24h | 3t/24h | 5t/24h | 10t/24h | 15t/24h | 20t/24h |
| Cooling capacity(KW) | 6.9 | 13.65 | 19.8 | 30.6 | 63.2 | 85 | 118 |
| Input power (KW) | 4.69 | 7.7 | 11.3 | 16 | 34.1 | 43.25 | 57.95 |
| Diameter(mm) | 1380*900*1985 | 1500*1250*2000 | 1600*1300*2200 | 1700*1300*2250 | 2600*1500*3100 | 2600*1500*4100 | 2600*1500*4620 |
| Ice machine Weight (kg) | 930 | 1050 | 1280 | 1600 | 2750 | 3750 | 5200 |
| Sizeofremote condenser | 1528*1030*942 | 2828*1030*942 |
Freezer:Of high quality stainless steel for all water and ice contact surfaces providing corrosion
resistance ,all the material meet the HACCP REQU request .
Cutter:Stainless steel cutters driven
by gear motors are uniquely designed to pproduce cylindrical ice simply..
Control :Unique Vivid H-M Interactive control system with all failure and working status showing
alive in touch-screen .
The ice thickness could be adjusted by setting the icing time in the touch screen .
Technical parameters
Refrigerant:R404A(R717)
The evaporating temp./condensing temp.:-30°C/40°C
Ice tube external diameter:¢22 ¢28 ¢35 ¢42
Standard ambient/Water Temp.30 °C /20 °C
