Flat Sheet Forming Machine Bending Machine
Machine
Decoiler
Forming
Cutting
Bending
Panel
Main Technical Specification
Size: 6400mm × 1300mm × 1400mm
Total Weight: about 5000kgs
Thickness of the coil: 0.3-0.6mm
Usage: Widely used as wall
Controlling System: PLC
Main Motor Power: 5.5KW
Hydraulic Power:3.0KW
Working Speed: 8000-12000mm/min
Protective Cover:Ensure the safety in working production
Materials of Rollers:45# steel,surface chromed
Driving Chains:12A-1-GB/T1243-97
Materials of Shafts:45# steel,surface,galvanized
Materials of Cutting Blade:Cr12Mov,quenched
Side Panels:Q235 carbon structural steel, surface galvanized
Driving Sprocket:45# steel,12A sprocket,surface galvanized,quenched(teeth parts)
Driving Gear:45# steel,surface galvanized,quenched(teeth parts)
Frame Structure:Q235 carbon steel subastral,surface galvanized
Type
Type |
Feeding Width
|
Effective Width
|
Groove Depth |
Thickness |
Usages |
SX-840 |
1000mm |
840mm |
25mm |
0.3-0.6mm |
Widely used as roof and wall |
SX-900 |
1000mm |
900mm |
15mm |
0.3-0.6mm |
|
SX-930 |
1000mm |
930mm |
14mm |
0.3-0.6mm |
|
SX-1000 |
1250mm |
1000mm |
35mm |
0.3-0.6mm |
Packing:container
Shipping Terms:FOB Dalian,CIF,CFR
Our Company
We are a professional manufacturer of various cold roll forming machines in good quality with a competitive price. The excellent equipment and prefect after-service system are highly praised by the customers home and abroad. All of the products have passed the CE and are sold to many countries as South America, Middle Asia and Europe. There are ten experienced engineers in the work team. With CNC manufacturing machines, we ensure the precision of every part and to be finished in a very short time. Meanwhile, we also provide services of steel structural construction projects. If you have any questions in technical or want to contract a construction of structural steel products, please contact us without any hesitation. We will help you solve all the difficulties and offer you the best solution. We are sincerely looking forward to cooperating with you soon !
Our Certificates
Our Customers
Q:Wy I choose your company?
A:Our company was established in 1992,export experience about 20 years.We can ensure the machine quality and price.
Q:Can you accept OEM?
A:We can accept OEM.
Q:Can you produce machine as our requirement?
A:Sure,we have professional and development personnel,if you provide the relevant information,we can produce.
Q:Can you pay on delivery?
A:No,but if the amount is big,you can pay the deposite first,the balance before our shipment.
Q:What is your MOQ?
A one set.
Payment term: T/T ,30% deposit in advance,the balance 70% before our shipment.
Delivery time: Within 30 workdays after receiving 30% deposit.
Warrantee period:3 years.During 3 years, all the damaged parts can be changed into new ones only if the buyer sends the damaged ones back, but the express cost is afforded by the buyer(man-made damage is not included).
Training: If the buyer needs us to go to the project site abroad for training, the buyer affords the ticket, visa, hotel and meals, and the salary $150/day/person. The training period has to be within 15 days.
