High Pressure Polyurethane Insulation Painting Machine
As a kind of high pressure polyurethane equipment, the polyurethane insulation painting machine is ideal spray painting equipment used for architectural coating.With an air-pressurized spray gun, the painting machine can be applied to spray polyurethane coating onto the surface, outer wall and roof of warehouse.
Thanks to innovative technology, the high-pressure spray gun can keep low volume feed rates while achieving high-pressure spray power. So the spraying coverage of products sprayed will be improved, and it is not likely to overspray. As to electrostatic spray painting of car body panels, bike frames, electric tools, guardrails, etc, the spray gun is also applicable.
With the aforementioned advantages, you will surely be satisfied with our company’s products.
CSPU High-Pressure Polyurethane Spray and Perfusion Machine | |
Standard Configuration | |
Mainframe |
1 set |
Spray Gun |
1 set |
Heating and Preserved Pipe |
15m |
Connecting Pipe for Spray Gun |
1.5m |
Max. Pipe Length |
90m(optional) |
Transfer Pump |
2 sets |
Technical Parameter | |
Material Ratio |
1:1(mixed) |
Power Source |
380V 50/60Hz 3 Phases electric (or according to your requirement) |
Air Source |
0.5-0.8 Mpa (70-120psi)≥0.9m³ /min |
Purging |
Automatic pneumatic, solvent-free |
Output |
4-8kg/min |
Heating Device Power for Material |
3,000W×2(or optional: 4,500W×2 |
Heating Power for Pipe Heating |
3,500W |
Single Component Output Pressure |
5-10Mpa (700-1,500psi) |
Heat Temperature |
80℃ |
Shipping Parameter | |
Weight |
125kg |
Volume |
800×700×1,100(mm) |
As widely used painting equipment, the polyurethane insulation painting machine can sprary architectural coatings onto wall and metal evenly, forming a dense coating on them, Polyurethane is the main spraying material for our polyurethane insulation painting machine, and it is sprayed onto the surface of outer wall or roof after atomized in high pressure. The painting machine can output 4 to 8kg polyurethane coating in a minute, which is not likely to be done with a traditional air spraying machine, so it can reduce the times of spraying. With high output pressure, this product can produce 5-10 MPa (700-150psi) single component output pressure.Due to the excellent surface quality, the coating is flat and smooth without any brush mark.The power source adopted is the 380V, 50/60Hz standard electrical configuration, and it is also free to be adjusted according to your requirements.
With such advantages, we believe that our products will be your first choice.
As an experienced polyurethane insulation painting machine manufacturer in China, our company provides a wide range, of products, including steel frame and roof forming machine, guard rail forming machine, spiral steel silo forming machine, and much more.
Yingkou Sanxing Roll Forming Machine Co.Ltd is the earliest manufacture of trailer arch roof machine in China since 1992. The only one who have got engineering qualification. Not only we are professional in machinery but also experienced in project designing. Welcome to visit us any future time.
1) Life time guarantee for whole machine except of bearing parts.
2) 24 hours technical support by e-mail.
3) Use-friendly English manual and videos.
