Jiujiang Ideal Imp. & Exp. Co.,Ltd is specializing in ice machines, cold room project, refrigeration
equipments items for more than 8 years in China since 2007. And the brand name "Icefocus" has
been registered for developing our business and agents in the world. We are supplying
"ICE MACHINES" including the following items:
(1) Flake ice machines: Fresh Water system 500kg/24hour to 60Ton/24hour.
Sea Water System 1Ton/24hour to 20Ton/24hour.
(2) Plate ice machines: 3Ton/24hour to 15Ton/24hour.
(3) Tube ice machines: 2Ton/24hour to 30Ton/24hour.
(4) Cube ice machines: Commercial Cube Ice Machines 23kg/day to 1000kg/day;
Industrial Cube Ice Machines 2Ton/24hour to 20Ton/24hour.
(5) Block ice machines: 1Ton/24hour to 20Ton/24hour.
Thanks for remembering our brand "ICEFOCUS" ,
Hight Quality Ice Machines and Cold Rooms Spokesman !
Our Brother Company "Hongkong Ideal Refrigeration Equipment Ltd."
Industrial Flake Ice Machine is designed to be modularized for easy maintenance. The evaporation tank of this machine is made of stainless steel SUS304 or carbon steel Chromium upon the user's requirements. The ice is very dry, pure, powerless, uneasy blocking. PLC controlling system can automatically control the whole process of producing ice with alarm of lacking water, full ice, high/low pressure, and motor reverse rotation protection so as to guarantee the machine run stably with less faults. The scratch-style ice dropping system inside machine ensures constant working with minimum power consumption. The patent processing technology allows for highly effecient heating transfer and energy saving.
The industrial flake ice machine always used in the field such as aquatic food & meat product processing, leather processing, fowl butchering, dye chemical industry, mines, concrete construction project,,etc.
|
Model
|
JJF100WF-A |
JJF150WF-A |
JJF200WF-A |
JJF250WF-A |
Ice Production Capacity |
10000kg/hour |
15000kg/hour |
20000kg/hour |
25000kg/24h |
Refrigerating Capacity |
51.5 KW |
106.6 KW |
113.6 KW |
154.8 KW |
Power System |
380V-50Hz-3P |
380V-50Hz-3P |
380V-50Hz-3P |
380V-50Hz-3P |
Input Power |
29.17 KW |
55.47 KW |
65.57 KW |
77.25 KW |
Diameter Of Water Supply Pipe |
3/4" |
3/4" |
3/4" |
3/4" |
Net Weight |
1500 KG |
3200 KG |
4200 KG |
5000 KG |
Dimension Of Unit(L/W/H mm) |
2300*1650*1745 |
3200*2010*2061 |
3400*2180*2370 |
3800*2540*2452 |
Flake Ice Machine Notes:
(1) Besieds Standard Voltage, we can manufacture the ice machine with
200V/240V/400V/440V-60Hz-3P according to customers request.
(2) Standard Ambient Temperature: 25C. Water Supply Temperature 16C. Evaporating
Temperature -20C.
(3) Applicable ambient temperature 5C-40C. water supply temperature 0C-40C.
(4) This series products are applicable to fresh water, Refrigerant R404A ( for 500kg/day --
1000kg/day ice machine), Refrigerant R22 for 1500kg/day---3000kg/day ice
machines). If you choose R404A, please inform us in advance.
(5) The outer size includes ice storage bin size.
(6) Thickness of ice: 1.5mm-2mm
(7) The input power is given at standard voltage and working conditions and therefore is
only for reference.
(8) With the development of technology, the data are subject to change without notice.
