10 Ton/Day Water-Cooled Flake Ice Machine
US$ 28,000 - 35,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Capacity:
10 Ton/24hour
Place of Origin:
Jiangxi, China
Payment & Shipping
Payment Methods:
Port of Shipment:
GUANGZHOU/SHENZHEN/SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
New 1 Ton/24hour Air Cooled China Suppliers Small Commercial Ice Maker Flake Ice Making MachinesUS$ 5,000 - 6,500MOQ: 1 Set -
Hot Sale Heavy Duty Stainless Steel Industrial Ice Making MachineUS$ 72,000 - 85,000MOQ: 1 Set
-
Commercial Outdoor Marine Seawater Compact Ice Maker Flake Ice Making Machine ManufacturersUS$ 12,500 - 20,000MOQ: 1 Set
-
High Efficiency and Energy Saving Industrial Flake Ice Ice Shape and New Condition Ice Making MachineUS$ 35,000 - 40,000MOQ: 1 Set
-
New Type Hot Sale Concrete Large Capacity Ice Maker Flake Ice Machine From China SuppliersNegotiableMOQ: 1 Set
Condition
New
Capacity
10 Ton/24hour
Place of Origin
Jiangxi, China
Brand Name
Icefocus
Model Number
JJF100WF-A(B)
Ice Shape
Flake Ice
Voltage
380V-50Hz-3P
Power(W)
29.17 KW
Dimension(L*W*H)
2300* 1650*1745mm
Weight
1500 KG
Certification
Other, CE,SGS,ISO
Warranty
12 months
After-sales Service Provided
Engineers available to service machinery overseas
Welcome To : Jiujiang Ideal Imp. & Exp. Co.,Ltd.
For Ice Machines and Cold Room Products !
Thanks for remembering our brand "ICEFOCUS" ,
Hight Quality Ice Machines and Cold Rooms Spokesman !
Our Brother Company "Hongkong Ideal Refrigeration Equipment Ltd."
ICEFOCUS Ice Machine are trageted for the supermarket, distant fishing, industrial cooling, chemical dyes, edible ice, and other production areas. There are so many varieties models with different specifications for your reference and options.
Industrial Flake Ice Machine Units
Design, Material, Technology Characteristics:
Industrial Flake Ice Machine is designed to be modularized for easy maintenance. The evaporation tank of this machine is made of stainless steel SUS304 or carbon steel Chromium upon the user's requirements. The ice is very dry, pure, powerless, uneasy blocking. PLC controlling system can automatically control the whole process of producing ice with alarm of lacking water, full ice, high/low pressure, and motor reverse rotation protection so as to guarantee the machine run stably with less faults. The scratch-style ice dropping system inside machine ensures constant working with minimum power consumption. The patent processing technology allows for highly effecient heating transfer and energy saving.
Application Fields :
The commercial flake ice machine is particularly suitable for refreshing vegetables and foodstuff in supermarket and quick cooling for processing fishery products and butchery.
Details & Sepcifications:
For Ice Machines and Cold Room Products !
Thanks for remembering our brand "ICEFOCUS" ,
Hight Quality Ice Machines and Cold Rooms Spokesman !
Our Brother Company "Hongkong Ideal Refrigeration Equipment Ltd."
ICEFOCUS Ice Machine are trageted for the supermarket, distant fishing, industrial cooling, chemical dyes, edible ice, and other production areas. There are so many varieties models with different specifications for your reference and options.
Industrial Flake Ice Machine Units
Design, Material, Technology Characteristics:
Industrial Flake Ice Machine is designed to be modularized for easy maintenance. The evaporation tank of this machine is made of stainless steel SUS304 or carbon steel Chromium upon the user's requirements. The ice is very dry, pure, powerless, uneasy blocking. PLC controlling system can automatically control the whole process of producing ice with alarm of lacking water, full ice, high/low pressure, and motor reverse rotation protection so as to guarantee the machine run stably with less faults. The scratch-style ice dropping system inside machine ensures constant working with minimum power consumption. The patent processing technology allows for highly effecient heating transfer and energy saving.
Application Fields :
The commercial flake ice machine is particularly suitable for refreshing vegetables and foodstuff in supermarket and quick cooling for processing fishery products and butchery.
Details & Sepcifications:
| Model | JJF100WF-A(B) |
JJF150WF-A(B) |
| Ice Production Capacity | 10000kg/24hour |
5000kg/24hour |
| Cooling Capacity | 51.5 KW | 106.6 KW |
| Power System | 380V-50Hz-3P |
380V-50Hz-3P |
| Input Power | 29.17 KW |
55.47 KW |
| Diameter of Water Supply Pipe | 3/4" |
3/4" |
| Net Weight | 1500 kg |
3200 kg |
| Machine Size including ice storage size (mm) | 2300L*1650W*1745H |
3200L*2010W*2061H |
| Cooling Way |
Water Cooled |
Water Cooled |
Notes:
(1) Besieds Standard Voltage, we can manufacture the ice machine with
200V/240V/400V/440V-60Hz-3P according to customers request.
(2) Standard Ambient Temperature: 25C. Water Supply Temperature 16C. Evaporating
Temperature -20C.
(3) Applicable ambient temperature 5C-40C. water supply temperature 0C-40C.
(4) This series products are applicable to fresh water, Refrigerant R404A ( for 500kg/day --
1000kg/day ice machine), Refrigerant R22 for 1500kg/day---3000kg/day ice
machines). If you choose R404A, please inform us in advance.
(5) The outer size includes ice storage bin size.
(6) Thickness of ice: 1.5mm-2mm
(7) The input power is given at standard voltage and working conditions and therefore is
only for reference.
(8) With the development of technology, the data are subject to change without notice.
Our Machine and Factory:
More Machines:
Flake Ice Machine |
Cube Ice Machine |
Tube Ice Machine |
Plate Ice Machine |
Block Ice Machine |
