SX-1000-680 Self-drilling Screw Machine

SX-1000-680 Self-drilling Screw Machine thumbnail-1
SX-1000-680 Self-drilling Screw Machine thumbnail-2
SX-1000-680 Self-drilling Screw Machine photo-1
SX-1000-680 Self-drilling Screw Machine photo-2
US$ 30,000 - 60,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Liaoning, China
Brand Name:
China SANXING
Model Number:
sx-1000-680
Contact Supplier Request Quote Chat Now
Yingkou Sanxing Roll Forming Machine Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
DALIAN
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Liaoning, China
Brand Name China SANXING
Model Number sx-1000-680
After-sales Service Provided Engineers available to service machinery overseas



 SX-1000-680 self-drilling screw machine

Product Description

profile

This building construction making machinery have two part.

  1. 1. Punching and Forming machine

1) Size: 11000mm×1500mm×2100mm

2) Total Weight: about 10000KG

3) Total Power: 16KW

4) Punching power: 5.5KW;

5) Forming power is 7.5kw;

6) Cutting power is 3.0kw

7) Controlling system: CNC and PLC

8) Step of rollers: 13 steps

9) Amount of holes: 8

10) Distance of holes: 360mm

11) Diameter of holes: 8mm

12) Working speed: 8m/min

13) Material of rollers: 45# steel, quenched HRC 58-62

14) Material of roller shafts: 45# steel, quenched HRC 58-62

15) Material of cutting blade: Cr12, 1 Mov steel

16) Feeding Width: 1000mm

17) Effective Width: 680mm

18) Thickness of the coil: 0.8-1.5mm

19) Operating factor of the panel: 68%

20) Electric Standard: 380V / 50 HZ / 3 PHASES

21) Proper span: ≤32m



  1. 2. Curving machine

1) Size: 2600mm×1800mm×3000mm

2) Total Weight: about 4500KG

3) Power: 5.5KW+2.0KW

4) Radian of the bending: radius=3m

5) Working Speed: 3m/min

SX-1000-680 self-drilling screw machine

 SX-1000-680 self-drilling screw machineSX-1000-680 self-drilling screw machine





Company Information

Yingkou Sanxing Roll Forming Machine Co.Ltd is the earliest manufacture of trailer arch roof machine in China since 1992. The only one who have got engineering qualification. Not only we are professional in machinery but also experienced in project designing. Welcome to visit us any future time.

SX-1000-680 self-drilling screw machineSX-1000-680 self-drilling screw machineSX-1000-680 self-drilling screw machineSX-1000-680 self-drilling screw machine
