JUTA 30A Solar Charge Controller 12V 24V Auto PWM Charging With USB and LCD Display
US$ 10 - 12
MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Hubei, China
Brand Name:
JUTA
Model Number:
CM30D
Payment & Shipping
Payment Methods:
Port of Shipment:
Wuhan/Ningbo/Shenzhen/Shanghai/Guangzhou
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
New JUTA 50A Solar Controller With Backlight 12V 24V LCD DisplayUS$ 35 - 45MOQ: 1 Piece -
Wuhan Solar Charge Regulator New 30A 12V 24V With LED Indicators, Portable Use, 30A Solar Charge ControllerUS$ 10 - 15MOQ: 20 Pieces
-
JUTA 50A Solar Controller With Backlight 12V 24V LCD Display,2015 New Solar Charge RegulatorUS$ 35 - 45MOQ: 20 Pieces
-
2015 JUTA PWM LCD 30A Solar Charge Controller With Time Control and Backlight, Different Batteries Can be OptionalUS$ 16 - 22MOQ: 1 Piece
-
10A 20A Solar Charge Controller Price Cheap 12V 24V Auto With USB and LCD PWM ChargingUS$ 9 - 13MOQ: 1 Piece
Place of Origin
Hubei, China
Brand Name
JUTA
Model Number
CM30D
Application
Solar System Controller
Rated Voltage
12V
Maximum Current
30A
JUTA 30A Solar Charge Controller 12V 24V Auto PWM Charging with USB
Our Online Store: /store/341515
Product Description
Features:
| 1.Vivid LCD graphic symbols | 8.Battery Low-voltage(LVD) protection |
| 2.Intelligent PWM charging mode | 9.Adjustable control parameters |
| 3.Simple button operation | 10.Over-current protection |
| 4.Settable Operating mode of Load | 11.Battery reverse-discharge protection |
| 5.Automatic Identification of System Voltage level | 12.Battery reverse-connected protection |
| 6.One USB(5V/1A) Power Output(optional) | 13.For Three types of battery (Sealed,Gel,Flooded) |
| 7. Normal control,light control and light with time control | 14.Three stage Charging (Bulk,Absorption,Float) |
Detailed Images
Technical Parameter
| Rated Current | 30A |
| Rated Voltage | 12V/24V Auto |
| Solar Input | ≤50V |
| Float Voltage | 13.8V/27.6V |
| Absorption Voltage | 14.4V/28.8V |
| LVD | 10.7V/21.4V |
| LVR | 12.6V/25.2V |
| HVD | 15.5V/31.0V |
| HVR | 15.0V/30.0V |
| Charge/Discharge Voltage Drop | ≤0.3V/≤0.2V |
| No Load Loss | ≤20mA |
| USB Power | 5V/1A Max(optional) |
| Charging Mode | 3 step, PWM charge |
| Specification of Cable | AWG 7# (16mm2) |
| Working Temperature | -20℃~50℃ |
| Storage Temperature | -30℃~70℃ |
| Humidity | ≤90%, no condensation |
| Mounting Hole | 171mm×75mm --Φ5 |
| Dimension | 181mm×95mm×42mm |
| Weight | 380g |
