Specifications
solar powered irrigation controller1.PWM controller
2.Lighting and timer controlling
3.ISO9001 ROHS CE
High quality CE ROHS solar dc ac 50hz 2kw solar powered irrigation controller
Features:
- 32 bit MCU with high speed and high performance
- 12 bit A/D high-precision sampling to ensure accuracy
- Excellent EMC design
- Nominal system voltage automatic recognition
- High efficient Series PWM charging, increase the battery lifetime and improve the solar system performance
- Use MOSFET as electronic switch, without any mechanical switch
- Widely used, automatically recognize day/night
- Adopt graphics dot-matrix LCD screen and HMI (human-machine interface) with 4 buttons, integrated menu displaying and operation
Humanized design of browser interface, undertake every operating conveniently
Full control parameters setting and modification, diversified load control mode
Gel, Sealed and Flooded battery type option
Adopt temperature compensation, correction algorithm for charging and discharging parameters automatically and improve the battery lifetime
Electronic protection:
Overheating
over charging
over discharging
overload,and short circuit(LOAD)
Reverse protection(solar module and battery)
High quality CE ROHS solar dc ac 50hz 2kw solar powered irrigation controller
|
Model Data |
SI2024Z |
SI2024Z |
Model Data |
SI2024Z |
SI2024Z |
Rated current |
10A, 20A |
Installation cable area |
>3# AWG (<25mm2) |
||
Rated voltage |
12V/24V |
48V |
Operating temperature |
-20°C~50°C |
|
|
Maximum voltage of solar panel |
≤50V |
≤100V |
Storage temperature |
-30°C~70°C |
|
Float voltage |
13.7V/27.4V |
54.8V |
Humidity Requirement |
≤90%, No Condensation |
|
|
Low Voltage Disconnection |
10.7V/21.4V |
42.8V |
Size |
130mm×188mm×62mm |
|
|
Low Voltage Reconnection |
12.6V/25.2V |
50.4V |
Mounting hole spacing |
98 mm×178 mm --Φ5 |
|
No load loss |
<30mA |
Weight |
590g |
||
|
Loop voltage drop |
≤200mV |
|
|
||
Charging mode |
PWM Mode |
|
|
||
Temperature compensation |
-4mV/Cell/°C |
|
|
||
Notes |
Model suffix' Z' represent automatic identify system voltage level, 'T'represent controller with remote monitoring. |
||||
1. Q: Are you a factory or trading company?
A: We are a factory.
2. Q: Where is your factory located? How can I visit there?
A: Our factory is located in Guangzhou, China. You are warmly welcomed to visit us.
3. Q: Does your company also provide other solar products except solar charge controller regulator?
A: Yes, we also provide other solar products, like mono solar panel, poly solar panel, off grid solar inverter, solar Led light, battery, portable solar system, solar charger, solar junction box, DC fun and other accesories related to the solar power system.
4. Q: How can I get some samples?
A: Please connect me for samples, and my phone number: 86 18613076668.
5. Q: Can the price be cheaper?
A: Of course, you will be offered a good discount for big amount.
High quality CE ROHS solar dc ac 50hz 2kw solar powered irrigation controller
Buy 30A PMW Solar Controller info:
Payment Terms
T/T, L/C are the payment methods we accept at present.
Shipping
Material in stock can be produced (procedure 5-20days) right away after pre-payment confirmation. COSCO Mearsk MSCship to worldwide for safe shipping, don't worry about package damage or loss. It takes about 15-40 days to worldwide, Please note us your contact details include your phone number for easy contacting from shipping company officer.
For more product information, you can also click here:
Mono Solar Panel Off Grid Solar Inverter Battery DC Solar Lighting System AC Solar System Solar LED Light Solar Charge Controller
High quality CE ROHS solar dc ac 50hz 2kw solar powered irrigation controller
