Home > Manufacturing & Processing Machinery > Plastic Machinery > Injection Molding Machine > Economic Film Roll Slitting Rewinding Machine

Economic Film Roll Slitting Rewinding Machine

US$ 4,000 - 20,000 MOQ: 1 Set

Key Specifications

Get Latest Price

Condition:

New

Product Type:

Pe Film

Place of Origin:

Zhejiang, China

Contact Supplier Request Quote Chat Now

Ruian Ruigao Machinery Factory

Payment & Shipping

Payment Methods:

Port of Shipment:

NINGBO

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Product Type Pe Film

Place of Origin Zhejiang, China

Brand Name RG

Model Number LFQ-700A

Voltage 220V

Power(W) 6KW

Dimension(L*W*H) 2.4*1.5*1.7

Weight 2t

Certification CE

Warranty ONE YEAR

After-sales Service Provided Engineers available to service machinery overseas

Plastic Film Slitting Machine

1. Machine Introduction

This machine is suitable for slitting and rewinding such various roll materials as BOPP, PET, CPP, CPE,

PVC, aluminum foil laminated with film and paper, etc. And can cut edge, separate and cut material according

to different requirements during production.

2. Machine Advantages

1. Main Motor equipped with inverter for speed regulation.
2. Separated General Control Cabinet, more flexible and even easier operation.
3. Automatic EPC for unwinding, photocell is suitable for tracking the edge and/or
the line of material.
4. Equipped with air shaft for unwinding material loading, magnetic powder brake
5. Air shaft for rewinding (frictional cam shaft available for option), Magnetic powder
clutch for rewinding tension control
6. Equipped with air trim discharge conveying system.
7. Automatic meter counting device.
8. Pressure roller for rewinding to make rewinding roll more uniform.
9. Disk knife available for option.

3. Machine Parameters

Type	LFQ-700A	LFQ-1100A	LFQ-1300A
Max.Width of Mother Roll	700mm	1100mm	1300m
Max.Diameter of Mother Roll	φ 600mm	φ 600mm	φ 600mm
Width of Final Roll	50~700mm	50~1100mm	50~1300mm
Max.Diameter of Rewinding	φ 450mm	φ 450mm	φ 450mm
Internal Diameter of RollCore	76mm	76mm	76mm
Mechanical Speed	180m/min	180m/min	180m/min
Slitting and Rewinding Speed	160m/min	160m/min	160m/min
Tolerance of EPC	±0.5mm	±0.5mm	±0.5mm
Total Power	2.9Kw	3.7Kw	3.7Kw
Weigh t o f Machine	1300kg	1600kg	1900kg
Overall Dimension(L×W×H)	1570×2100×1500	1570×2500×1500	1570×2700×1500
