ST-1650VF-S Vacuum Sintering Furnace for Industry Heating
Product name &Model |
ST-1650VFS Vacuum Sintering Furnace |
|||
Use of furnace |
This furnace will be used for the sintering of the powder metallurgy,hard alloys,high proportion alloys,ceramic material,magnetic and cemented carbides. |
|||
Heating chamber size |
400x400x500mm WxHxD) |
|||
Maximum Temperature |
1650℃(Working time ≤1h) |
|||
Working Temperature |
500-1550℃ (continuously Working and adjustable) |
|||
Heating elements |
TUC-1700 U type MoSi2 heater |
|||
Temperature uniformity |
±5℃ (at 1000℃) |
|||
Temperature accuracy |
±0.5℃ |
|||
Heating rate |
0--20℃/min (adjustable) |
|||
Over temperature value |
Less than 3℃ |
|||
Temperature control and equipment manipulate |
30 segments programmable and PID auto control and reliable safety interlocking: Install computer communication module and RS485 communication interface, with the computer connection, to realize the remote full automatic control of temperature and manipulate.And implement paperless record on the temperature. |
|||
Temperature measuring |
B type thermocouple with two core(1 core used for temperature control, another core used for record) |
|||
Insulation materials |
lightweight alumina fiber Ceramic |
|||
Heating chamber structure |
Rectangle cube structure,constitute by lightweight alumina fiber Ceramic of refractory and Structural steel framework. |
|||
Furnace body(shell) structure |
Horizontal round appearance and double-deck steel structure.The outer layer and inner layer with 3 cm interval for pass circulating cooling water. |
|||
Cooling system of furnace |
Circulating water cooling + powerful fan cooling |
|||
Circulating water pump |
Centrifugal water pump,flow:8-10 ton/h,Delivery head:10m,(provide by users) |
|||
Cooling Blower |
Power:2.2KW;Rotating speed: 2900 r/min;Exhaust air rate:103200m3/h |
|||
Vacuum system and machine specifications |
Vacuum system composition by Rotary-vane vacuum pump and Roots vacuum pump.Rotary-vane pump model: 2X-70 Pumping Rate:70L/S; Roots pump model: RTO-600S, Pumping Rate:600L/s |
|||
Maximum vacuum degree |
5X10-1Pa |
|||
Electric control system |
By voltage regulator, SCR, and programmable temperature controller composition. |
|||
Protection function |
Self inspection and fault diagnosis, automatic protection, prevent maloperation functions; And with sound and light alarm prompt and have corresponding interlocking protection function.Such as: off the water, super temperature, heater over-current protection; Vacuum unit each equipment empty phase protection. |
|||
Working power |
AC 3-phase, 380-415V;50/60Hz |
|||
Rated power |
Total power: 65KW (Heat power:33KW; Vacuum system power:12KW; Cooling system power:10KW; Auxiliary power:10KW) |
|||
Equipment footprint |
22 sq.m. |
|||
Net weight |
1950KG |
|||
Freebies |
Pipeline sealing ring 1 set |
Vacuum Unit Grease 1 Pc |
Vacuum pump sealing ring 1 set |
|
