2015 CE Approval 1700 Celsius atmosphere sintering muffle furnace with programmable and PID auto controll
1.Applications of Atmoshpere Sintering Muffle Furnace :
Atmosphere sintering muffle furnace can protect material from oxidation and decarburization with flowing Nitrogen, Argon and other inert gas.
1700 Celsius atmosphere sintering muffle furnace is an ideal equipment for sintering, reducing with inert-atmosphere in the labs of university, Research Institution and industrial company.
2.Features of Atmophere Sintering Muffle Furnace Features:
1700C Atmosphere sintering muffle furnace Atmosphere sintering muffle furnace have below outstanding feature:
1: Better leak tightness.
2: Better heating preservation,
3:Atmosphere can be controlled.
4:Safety and explosion provention.
5: Precise temperature control.
6: Max Vacuum can up to -0.1Mpa
3.Ceramic Sintering Furnace Data:
Product Name: |
Atmosphere sintering muffle furnace |
Code No# |
ST-1700MVA-II |
Max Tempearture: |
1700C(<3 Hours) |
Working Tempearature: |
1650C(Continuous) |
Max Vacuum |
-0.1MPa |
Inner chamber Size: |
200*150*150mm or customizatable |
Furnace structure: |
Double Shells with fan cooling |
Temperature Controller: |
50 Segment programmable and PID auto control |
Temperature Accuracy: |
+/-1 °c |
Heating Elements: |
MoSi2 Heating Elements |
Heating Rate: |
20°c/Minutes(Suggestion<15°c) |
Thermocouple: |
B Type(0-1820C) |
Rated Power: |
4KW |
Rater Voltage: |
AC 380V (50/60hz) |
Net Weight: |
182kg |
Dimension; |
860*660*1185mm |
Certification: |
CE&ISO9001:2008 |
Standard package included with the furnace:
Thermal couple |
1 pc |
Inlet/outlet,valves |
1 set |
Flow meter |
1 pc |
Vacuum gauge |
1 pc |
Vacuum pump |
1 pc |
Furnace door block |
1 pc |
Thermal gloves |
1 pair |
Operation manual |
1 pc |
Standard Sizes:
Model |
Chamber size(WxHXYmm) |
ST-1700MVAM |
100x100x100mm(4.8"x4.8"x5.2") |
ST-1700MVA-I |
150x150x150mm(6"x6"x6") |
ST-1700MVA-II |
150X150X200mm(6"x6"x8") |
ST-1700MVA-III |
200x200x200mm(8"x8"x8") |
ST-1700MVA-IV |
200x200x300mm(8"x8"x12") |
ST-1700MVA-V |
250x250x300mm(10"x10"x12") |
ST-1700MVA-VI |
300x300x400mm(12"x12"x16") |
ST-1700MVA-VII |
400x400x400mm(16"x16"x20") |
ST-1700MVA-VIII |
400x400x500mm(16"x16"x20") |
ST-1700MVA-IX |
600x600x600mm(24"x24"x24") |
4.Term of payment:
50% payment by T/T after sign the contract, 50% payment by T/T before shippment .
5.Why us
About Zhengzhou Sutong Electric Company Factory
We are a bigger furnace factory in North of China, our 80%furnace is for export, so we have best after service and do in time service, our factories can make sure that time and quality can be greatly improved.
After sales service of electric gold melting furnace
The seller provide guarantee free for 1 year from the date of shipment.
The seller is not responsible for the problem caused by wrong operation, and working environment couldn’t meet the working condition.
The seller will give technical instruction when the buyer need
Our company is comprehensive company specialized in manufacturing and trading electric resistance furnaces
Notice : We our company can supply different sizes gold melting furace to customers accroding your demands on it .
Welcome to contact us if you are interest in our furnace , Vera Zuo will supply exclusive service !!!
