Help CenterHigh Quality Stainless Steel Cartridge Filter
Related Products
-
Liu Tech Air Compressor Air Oil SeparatorUS$ 15 - 150MOQ: 2 Pieces -
Coalescer Cartridges for Aviation and Industrial UseUS$ 35 - 55MOQ: 5 Pieces
-
Air Filtration Panels in Stationary Engines,US$ 25 - 55MOQ: 10 Pieces
-
Air Filtration Panels in Stationary Engines,US$ 15 - 30MOQ: 10 Pieces
-
ARGO Suction FiltersUS$ 25 - 40MOQ: 5 Pieces
Specifications
1.Stainless steel cartridge2.Easy to operate
3.Large-area, heavy-duty baskets
4.SS 316 & SS 304
Stainless steel cartridge filter
Stainless steel cartridge-filter housings are rugged and low in cost.
They hold many cartridges, in 10-inch, 20-inch, 30-inch, or 40-inch
lengths, using industry standard designs (222, SOE, or DOE). The unique,
“quick-opening” clamp design uses a standard gasket.
Standard Features
Low pressure drop
Permanently piped housings are opened without disturbing the piping or
requiring tools
Quick-opening, clamp-type cover
Carbon or stainless steel housings
Adjustable-height tripod legs
Holds many cartridge elements
Accommodates cartridge elements in many lengths: 10”, 20”, 30”, 40”
125-psi rated housing
3/4-inch clean-dirty/gage ports
2-inch female NPT ports
V posts or threaded-center posts
Standard hardware V-post and spring seals are 316 stainless steel.
O-ring seals: Buna N, EPR, Viton®
Based on housing only. Fluid viscosity, filter cartridge used, and expected dirt loading
should be considered when sizing a filter.
