Help CenterHarmsco PP-BB-10-1 Big-Blue Filter Cartridges
Related Products
-
Harmsco PP-HC/40-1 Filter Cartridges for Drinking WaterUS$ 15 - 75MOQ: 5 Pieces -
Harmsco PP-HC/170-1 Filter Cartridges Substantially Removes Cryptosporidium, Giardia CystsUS$ 15 - 75MOQ: 5 Pieces
-
High Porosity Sintered Materials Filter ElementUS$ 30 - 200MOQ: 5 Pieces
-
PE Mini Cartridges(PE/HDPE Construction)US$ 10 - 200MOQ: 5 Pieces
-
PE Membrane Filter CartridgesUS$ 10 - 200MOQ: 5 Pieces
Specifications
1.FDA listed materials for use in potable water and liquid food applications2.Low Pressure Drop
3.Long Filter Life
Harmsco Absolute Rated Filter Cartridges for Safe, Cyst-free Drinking Water
Substantially removes Cryptosporidium, Giardia Cysts, harmful organisms, sediment, silt, turbidity and more!
Features & Benefits
1.Absolute rated one micron filter media removes cyst-sized particles for safe, cyst-free drinking water.
2. Pleated polypropylene filter media provides more surface area for longer filter life and increased particle removal.
3.FDA listed materials for use in potable water and liquid food applications.
4.End caps, center tubes and media are thermally bonded as one integral component for added strength and to provide superior end sealing.
5.Full product line for standard, Big-Blue and Hurricane®filter housings.
6.Economical cartridges from the value leader in the industry!
Cartridge Types & Product Codes
POLY-PLEAT™ cartridges are available in Standard, Big-Blue and Hurricans models for a variety of filter housings
| Product Code | Micron Rating | Media (sq. ft.) | Type | Length | O.D. | No./ Case | |
| Standard (2-3/4” O.D.) | PP-S-1 | 1 absolute | 3.7 | Standard | 9-3/4” | 2-3/4” | 24 |
| PP-D-1 | 1 absolute | 7.5 | Standard | 19-1/2” | 2-3/4” | 24 | |
| PP-T-1 | 1 absolute | 11 | Standard | 29-1/4” | 2-3/4” | 24 | |
| PP-20E-1 | 1 absolute | 7.5 | Standard | 20” | 2-3/4” | 24 | |
| Big-Blue (10” & 20”) | PP-BB-10-1 | 1 absolute | 8 | Big Blue | 9-3/4” | 4-1/2” | 8 |
| PP-BB-20-1 | 1 absolute | 16.5 | Big Blue | 20” | 4-1/2” | 4 | |
| Hurricane(40, 90, 170) | PP-HC/40-1 | 1 absolute | 27 | Hurricane | 9-5/8” | 7-3/4” | 1 |
| PP-HC/90-1 | 1 absolute | 58 | Hurricane | 19-1/2” | 7-3/4” | 1 | |
| PP-HC/170-1 | 1 absolute | 100 | Hurricane | 30-3/4” | 7-3/4” | 1 |
specifications
Micron ratings: One micron absolute for cryptosporidium and giardia cysts.
Filter media: Meltblown polypropylene inner layer with outer layers of polypropylene scrim material for support.
Center tubes: Rigid PVC with perforations, or molded polypropylene.
End caps: Pliable PVC with sealing surface built-in.
Temperature: 140°F / 60°C temperature limit.*
Flow rates: Up to .5 gpm/ft media.
Netting: Polypropylene netting standard for 2-3/4” O.D.; Big-Blue cartridges use polyethylene netting.
Shrink wrap: Standard for all POLY-PLEAT™ cartridges
Low Pressure Drop
Initial pressure drop using POLY-PLEAT™ cartridges is exceptionally low due to our pleated design and increased
surface area. Pressure drop data is shown below, calculated for new cartridges in clear water.
Long Filter Life
POLY-PLEAT™ cartridges are ideal as final filters for municipal water filtration without pre-filtration. In high turbidity
water, pre-filtration is recommended using Harmsco®
sediment cartridges with two- or three-step filtration, depending on the source water. POLY-PLEAT™ cartridges provide
long filter life due to their pleated design and increased surface area.
