Specifications
1.excellent chemical compatibility2.superior flow per unit area
3.different PE pore sizes are available
PE Membrane Filter cartridges
PE membrane filter cartridges are highly retentive hydrophobic filters with all polyethylene constructions that have been specially designed for critical liquid and gas sterilization applications. The filter provides excellent chemical compatibility and superior flow per surface area. No adhesives, binders, or surfactants are used in the manufacturing process and all
cartridges are rinsed with high-purity water to reduce extractable and downtime.
The naturally hydrophobic PE membrane is idea alternative to PTFE membranes for some special aggressive chemicals, solvents, and gas filtration. In addition, the all polyethylene construction offers the compatibility of gamma sterilization.
All filter cartridges are 100% integrity tested to ensure filter performance. They are manufactured under ISO 9001 certified quality system.
Specifications
| Materials of Construction | Membrane: Hydrophobic Polyethylene Media Supports: Polyethylene Core, Cage, End Caps: Polyethylene O-Rings: Silicone, EPDM, Fluoro-Elastomer, Buna N, |
| Nominal Dimensions: | Lengths: 5 in. (13 cm), 10 in. (25 cm), 20 in. (50 cm), 30 in. (76 cm), 40 in. (102cm) Diameter: 2.75 in. (70mm) |
| Effective Filtration Area: | 6.5Ft2(0.6m2 per 10" cartridge element |
| Available Ratings: | 0.2um (0.003um Gas), 1.0um, 1.5um, and 2.5um |
| Operating Conditions: | Maximum Forward Differential Pressure: 4.0 bar (58 psid) at 20 °C Maximum Reverse Differential Pressure: 2.5 bar (36 psid) at 20 °C Maximum Operating Temperature: 60° C |
Applications
| Gas Sterilization | Pharmaceuticals | Tank vent |
| Biologicals | Solvent filtration | Fermentation |
| Vaccines | Biologics | Gas Filtration |
| PTFE alternative | Fine Chemicals |
certification
