48 volt lithium ion battery 20ah for 3kw motor+BMS+case TB-4820F wholesale price

Specifications

1C-10C discharge current
Environmental friendly
High performance
No memory effect
Long lifespan

Moped scooter battery with Good PCB controlling system can avoid overcharge and over-discharge  well



Detailed info of Topband lifepo4 battery 48V 20AH are as below:



Model:	TB-4820F
Type	LiFePO4 battery with PCM
Nominal voltage:	51.2V
Typical capacity	20Ah
Internal Impedance(1kHz AC)	<250mΩ
Max Charge voltage	58.4±0.05V
Discharger cut-off voltage	36±0.05V
Max charge current	20A
Max continuous discharge current	30A
Max pulse discharge current	40A (2 s)
Charging temperature	0°C~45°C
Discharging temperature	-20°C~60°C
Storage temperature	-20°C~45°C
About 2000 cycles to 80% with 100% DOD under 20 °C~25°C
Size(L*W*H)	260*155*190mm
Weight:	approx.11.5Kg
Application:E-bike, E-motor, E-scooter, UPS, E-wheelchair, Vacuum cleaner etc.
We can offer model: 48V 10Ah,30AH,50AH .





protection board:

Compared with SLA battery,lifepo4 battery has many advantages:

1Long cycle life:up to 2000 times

1. Green: Non-Toxic, comfort to RoHS.

2. Long cycle life: > 2000 cycles, while Sealed Lead Acid batteries only 750 cycles and NiMh batteries only 500 cycles)

3. Safety

The safest battery in the world till now, which does not burn with 30V charge voltage and it does not explore when you puncture the battery. UL and CE approved.

4. Light weight and smaller dimension

The dimension is smallest and the weight is lightest when compare with other battery. 1/3 weight of SLA, 65% weight of NIMH.

5. Great capacity and more powerful, rechargeable battery

High discharge current, 1C continuous, 3C pulse for normal cells and 20 C for special design

We can install many single cells in series and in parallel and it can fully discharge

6. Good thermal stability: - 40°C to 70°C

7. Back fast charge, good consistence, no memory effect, can equip battery charger.

Can be recharged anytime, no reduction of the capacity

7. Widely application, customize solutions, mass production, OEM/ODM/buyer label provided, factory passed TS 16949, ISO 9001:2008.
