Help CenterVelcon CO-718 Series Filter Cartridges Replacement for Fuel and All Kinds of Oil Treatment
Related Products
-
Replace Velcon SO Series Oil Water Separator ElementUS$ 30 - 200MOQ: 10 Pieces -
Velcon SO Series Oil Water Separator CartridgesUS$ 30 - 200MOQ: 5 Pieces
-
Oil Water Separator Cartridges (sino-korea Joint Enterprise)US$ 30 - 200MOQ: 5 Pieces
-
Oil Water Coalescer/separator Filter Cartridges (sino-korea Joint Enterprise)US$ 30 - 200MOQ: 5 Pieces
-
Replace Parker HCP Series Coalescer Filter Element For Industrial ApplicationsUS$ 30 - 200MOQ: 10 Pieces
Specifications
1 Highest adsorptive area2.Perforated metal center tube
3.Hoisting handles for easy changeout
4.For assured sealing
CO-718 Series Cartridges for Fuel and Oil Treatment
The Velcon CO-718 Series cartridges are intended for use in all clay treatment vessels designed for nominal
7” x 18” cartridges. The treatment/purification medium is a special blend of low volatile materials (LVM) fuller’s
earth compounded to provide the optimum balance between adsorptive capacity and water resistance.
With their ability to prevent channeling and their high particle structure stability, the cartridges assure reliable
performance and long life in the most exacting process applications.
Jet Fuel Treatment – One of the most common uses for clay cartridges is to remove surfactants
from jet fuels. Surfactants can carry over from the refinery process or be picked up when the jet fuel travels
through multiproduct pipelines (corrosion inhibitors, gasoline additives, etc.). Surfactants will eventually disarm
filter/separators, which are primarily designed to remove water from the jet fuel. By removing surfactants from
the fuel, the clay cartridges protect the downstream filter/separators. Since clay removes the surfactants by
an adsorbent (adhering) action, the fuel residence time, or time in contact with the clay, is very important for
proper fuel treatment. Normally, a flow rate of about 6.5 gpm per 7” x 18” cartridge is ideal for jet fuel.
Construction
CO-718CE is a rugged canister cartridge featuring aluminized steel endcaps and center-tube, polyester felt
outerwrap and both interior and exterior media migration barriers. A wire bail provides for easy installation and
removal. Buna-N gaskets at each end assure tight sealing. The improved construction offers high resistance to transit
or handling damage and to differential pressures up to 100 psi.
Specification
Length : 18″
Outer Diameter : 7″
Center Diameter : 2 1/4″
Collapse Strength : 100 psi
Application
Lubricating Oils Quench Oils
Vacuum Pump Oils Hydraulic Fluids
Jet Fuels Insulation Oils
Diesel Fuel Biodiesel Fuel
Aluminum and Stainless Steel Rolling Oils
We could custom many sizes filter element, and OEM service is available.
If you are interested in our products and want to know more information about it,please contact us. Any question or suggestion please feel free to tell us .that will be appreciated !
