Specifications
M30H linear wood cnc router:1.Imported square orbits
2.Germany ballscrew
3.Ncstudio control
4.Auto-tool ,vacuum suction.
M30H linear wood cnc router
Specification:
Model |
M30H |
X Y working area |
1500*3000mm |
Z working area |
200mm |
Table size |
1680*3500mm |
Max feeding |
>30m/min |
Work holding |
by suction |
Processor |
DSP |
Interface |
USB |
Command |
G code |
Surroundings for software |
DSP |
Power(not include spindle) |
4000w |
Working Voltage |
380v/50hz |
Spindle power rate |
5(water cooling) |
Spindle rotating speed |
18000rpm/min |
Drive motor |
servo |
Equipment Features
A.Separate keyboard control system, easy to lean and convenient to operate, the customers are ableto master the application in a short time.
B.Intelligent anti-transgree-process protection system, this function could prevent machine crashes when the design zone is
beyond the process zone. Control the process speed, so can increase the efficiency , prolong the
cutter life and increase the rate if finished products.
C.Dust-suction system:the dust suction system could absorb the saw dust and keep machines clean, which maintains equipments as well; the dust suction system take place of the physical flat fixation which
save the time of load and unload time of slabs.
D.Advanced file pretreatment function can correct the error in the files and is compatible with the
process codes of multiple national and international software, advanced 3D space curve prediction
algorithm can make sure of the evenness of polyline and the speed and precision of curve lines.
Details:
SAMPLES:
