Specifications
cnc woodworking machine:4.5Kw imported bearing water cooling spindle
2.vacuum table,
3.DSP control system
4.Step motor
CNC Woodworking Machine 1524 :
1.Whole Steel structure,
2imported square orbit,
3.ballscrew for z axis, gear-wheel for x axis and y axis,
4.u flash disk DSP control system,
5.Wentai Software and Type3 Software,
6.4.5Kw imported bearing water cooling spindle,
7.vacuum table,
8.1 no oil vacuum pump and dust collector system with 8 zones separately control, dust cover,
9.10 cutters( φ6, φ12.7), 2 collets
CNC Woodworking Machine 1524 Technical parameter:
Model |
HD-1524 |
XY working area |
1500X2400mm |
Z working area |
>200mm |
Table size |
1650X2500mm |
Max travel speed |
8m-30m/min |
Processor |
DSP/Frequency 100MHz |
Interface |
PCI card or USB handle |
Command |
G code*.u00*.mmg*.plt |
Surroundings for software |
Windows98/2000/xp |
Power(not include the spindle) |
1500-2000W |
Working voltage |
AC220V/50Hz |
spindle power rate |
2.2-6.6KW |
spindle rotating speed |
1800-24000rpm/min |
Drive motor |
Steper or servo |
The working samples:
Our services:
1.The processing demo video and E-catalogue will be mailed as your request.
2.One year free warranty under normal using.
3.Free training to guarrantee you can operate machine correctly.
4.OEM service and customized service will be supplied.
In addition, we have woodworking engraver, relief engraver, cylinder craft wood engraver, special mould engraver, stone engraver, advertising machines, laser engraving/cutting machines and so on.
we can make carving machines with all specifications to meet user's requirements.
Thank you for your visiting the product of HongDa BoKe!
Your satisfaction is our pursuit.
