Low tension copper conductor 4 core 35mm2 xlpe fire resistant cable price
APPLICATION
This cable is designed for areas where the integrity of the electrical properties circuit is critical in maintaining power supply. Applications can be found in emergency lightings, control and power circuits, power stations, fi re alarm systems, underground tunnels, communications systems, sewage treatment plants, lifts, escalators, and high-rise buildings.
STANDARDS
Basic design to IEC 60502-1/BS 7846
VOLTAGE RATING
600/1000V
CABLE CONSTRUCTION
Conductor: Plain annealed copper wire, stranded according to IEC(EN) 60228 class 2.
Insulation: Mica glass tape covered by extruded cross-linked XLPE compound
Cabling: The cores are cabled together in concentric layers with suitable non-hygroscopic fillers.
Inner Sheath(optional): Thermoplastic LSZH compound type LTS3 as per BS 7655-6.1
Armouring(optional): Galvanized steel wire armour
Outer Sheath: Thermoplastic LSZH compound type LTS3 as per BS 7655-6.1 (Thermosetting LSZH
compound type SW2-SW4 as per BS 7655-2.6 can be offered.)
COLOUR CODE
Insulation Colour
2 - Core: (Brown & Blue)
3 - Core: (Brown, Black & Grey)
4 - Core: (Brown, Black, Grey & Blue)
Sheath Colour
Orange (other colors upon request)
Physical AND THERMAL PROPERTIES
Temperature range during operation (fixed state): -30°C – +90°C
Temperature range during installation (mobile state): -20°C – +50°C
Minimum bending radius: 8 x Overall Diameter (unarmoured cable)
10 x Overall Diameter (armoured cable)
CONSTRUCTION PARAMETERS
Conductor |
FFX400 1mRZ1-R |
FFX400 1mRMZ1-R | |||||
No. of Core X Cross Section |
No./ Nominal Diameter of Strands |
Dia. of Conductor |
Nominal Insulation |
Unarmoured Cable |
Armoured Cable |
||
Nominal Overall Diameter |
Approx. Weight |
Nominal Overall |
Approx. |
||||
No*mm2 |
No./mm |
mm |
mm |
mm |
kg/km |
mm |
kg/km |
2 Core | |||||||
1.5 |
7/0.53 |
1.59 |
0.7 |
12.2 |
150 |
15.3 |
390 |
2.5 |
7/0.67 |
2.01 |
0.7 |
12.6 |
180 |
16.5 |
450 |
4 |
7/0.85 |
2.55 |
0.7 |
14.7 |
250 |
17.6 |
525 |
6 |
7/1.04 |
3.12 |
0.7 |
16.2 |
290 |
18.8 | 620 |
10 |
7/1.35 |
4.05 |
0.7 |
17.1 |
450 |
21 | 800 |
16 |
7/1.70 |
5.1 |
0.7 |
19.2 |
550 |
23 | 1100 |
25 |
7/2.14 |
6.42 |
0.9 |
20 |
680 |
27 | 1480 |
35 |
19/1.53 |
7.65 |
0.9 |
22 |
940 |
30 | 2000 |
50 |
19/1.78 |
8.9 |
1 |
24 |
1250 |
33 | 2450 |
70 |
19/2.14 |
10.7 |
1.1 |
27 |
1700 |
37 | 3200 |
95 |
19/2.52 |
12.6 |
1.1 |
31 |
2300 |
42 | 4350 |
120 |
37/2.03 |
14.21 |
1.2 |
36 |
3150 |
48 |
6500 |
For detailed data for this cable, welcome to contact us 7*24 hours.
