Help CenterCopper Conductor Building Household Electrical Wire
Related Products
-
2.5mm 4mm 6mm 10mm 16mm 25mm Different Colors Cu PVC Single Core Wire CableUS$ 0.02 - 17.5MOQ: 10000 Meters -
4mm PV1-F Tinned Copper Conductor XLPE Insulation DC Cable Solar Cable Flexible CableUS$ 0.45 - 12.38MOQ: 10000 Meters
-
PVC Insulated Copper Conductor Electric Wire Plastic Cover Quality ChoiceUS$ 0.05 - 5MOQ: 100 Meters
-
PVC Insulated Copper Conductor 6 mm Electric WireUS$ 0.05 - 5MOQ: 100 Meters
-
PVC Insulated Copper Conductor House Wire Electric Cable Wire Supplier's ChoiceUS$ 0.05 - 5MOQ: 100 Meters
copper conductor building household electrical wire
PVC Insulated Copper Conductor Building Wire ACSR Aluminum Conductor Steel Reinforced PVC Insulated PVC Sheathed Control Cable
XLPE Insulated Al Conductor Overhead Cable Low Voltage Power Cable Medium Voltage Power Cable
copper conductor building household electrical wire
copper conductor building household electrical wire
Application
The product is applied to AC rated voltage 450/750V and below power plant laid(fixed)wiring. It's widely used in low voltage power lines,normal electrical equipment, instrumentation and telecommunication equipments.
Technical data
Rated voltage: 0.6/1KV
Highest working temperature of conductor: 90°C
Laying temperature:above 0°C
Minimum bending radius:6D
Specification
Nominal |
Conductor |
Nominal |
Max overall |
Condcutor |
Min insulated |
Weight |
||
Cu |
Al |
Cu |
Al |
|||||
1.5 |
1/1.38 |
0.7 |
3.3 |
12.1 |
- |
0.011 |
19.2 |
- |
1.5 |
7/0.52 |
0.7 |
3.5 |
12.1 |
- |
0.010 |
20.6 |
- |
2.5 |
1/1.78 |
0.8 |
3.9 |
7.41 |
11.8 |
0.010 |
30.8 |
15.0 |
4 |
1/2.25 |
0.8 |
4.4 |
4.61 |
7.39 |
0.0085 |
45.5 |
21.0 |
6 |
1/2.76 |
0.8 |
4.9 |
3.08 |
4.91 |
0.0070 |
65.0 |
29.0 |
10 |
7/1.35 |
1.0 |
7.0 |
1.83 |
3.08 |
0.0065 |
110.0 |
52.0 |
16 |
7/1.70 |
1.0 |
8.0 |
1.15 |
1.91 |
0.0050 |
170.0 |
70.0 |
25 |
7/2.14 |
1.2 |
10.0 |
0.727 |
1.20 |
0.0050 |
270.0 |
110.0 |
35 |
7/2.52 |
1.2 |
11.5 |
0.524 |
0.868 |
0.0040 |
364.0 |
150.0 |
50 |
19/1.78 |
1.4 |
13.0 |
0.387 |
0.641 |
0.0045 |
500.0 |
200.0 |
70 |
19/2.14 |
1.4 |
15.0 |
0.268 |
0.443 |
0.0035 |
688.0 |
269.0 |
95 |
19/2.52 |
1.6 |
17.5 |
0.193 |
0.320 |
0.0035 |
953.0 |
360.0 |
120 |
37/2.03 |
1.6 |
19.0 |
0.153 |
0.253 |
0.0032 |
1168.0 |
449.0 |
copper conductor building household electrical wire
1. Hebei Wanfang Wire & Cable Group Co., Ltd. established in 2004. Our main and advantage products include 35KV or lower XLPE insulated power cable, 1 and 3 KV PVC insulated power cable, 10 KV or lower aerial cable, pre-branch cable, control cable, computer cable, ACSR, AAC, building cable.
2. ISO 9001, ISO 14001, OHSAS 18001 Certificates.
3. Registered Capital: 218,000,000 RMB
4. Total building size: 40,000 m2
5. Total No. of employee: 316
Wooden drum, wooden-steel drum, Steel drum or as your request.
Delivery port: Tianjin/Qingdao/Shanghai
Delivery time: 15 days or as to the qty
Payment term: T/T,L/C
1. Q: Are you manufacturer or trading company?
A: We are Group company with 40000m² total building size, big production capacity.
2. Q:Can you provide Type Test Reports?
A: Yes we can provide type test reports issued by Chinese laboratories.
3. Q:What is your MOQ?
A: You are advised to confirm it with us directly as it’s based on different cable type.
Usually it’s 500 meters for Medium Voltage Cables.
10000 meters for electrical wire.
4. Q:How can I get your price list?
A: Please leave your contact way such as Email/MSN/Skype/Trademanager to us. We will contact to you and send our quotation sheet to you.
5. Q: Required mainly certificates?
A: Our products are certified by ISO9001/ISO14001/CCC/TUV etc.
