Indoor, Outdoor, Underground, Overhead, Computer, Instrument Usage Electric Cable Wire
US$ 2.28 - 17.5
MOQ: 5000 Meters
Key Specifications
Get Latest Price
Place of Origin:
Hebei, China
Brand Name:
Wanfang
Model Number:
YJV32, YJV42, YJV22
Payment & Shipping
Payment Methods:
Port of Shipment:
Tianjin Qingdao
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Standard and Specification as per Your Requirments, 1kV to 35kV Power CableUS$ 2.28 - 17.5MOQ: 5000 Meters -
Multi Core Security Control Cable 0.75mm Braided Copper Wire Shielded CableUS$ 3.15 - 17.5MOQ: 5000 Meters
-
PUR-CY Control Cables VDE Standard Tinned Copper Wire Screen CableUS$ 2.28 - 17.5MOQ: 5000 Meters
-
CY PVC/PVC /TCWB/ PVC Control Cable 300v Rvvp Shielded Flexible CableUS$ 2.28 - 17.5MOQ: 5000 Meters
-
YY PVC/ PVC Number Coded VDE Standard Electrical Cable ManufacturerUS$ 2.28 - 17.5MOQ: 5000 Meters
Place of Origin
Hebei, China
Brand Name
Wanfang
Model Number
YJV32, YJV42, YJV22
Type
Insulated
Application
Underground
Conductor Material
Copper
Conductor Type
Stranded
Insulation Material
PVC
Product Description
Indoor, Outdoor, Underground, Overhead, Computer, Instrument Usage electric cable wire
Flexible multicore cable, flame retardant and with reduced emission of corrosive gases.
Normative references:
| Italian standard: | CPT 007 | CEI 20-22 II | |||
| Colours code: | CEI UNEL 00722/ HD 308 |
Construction:
- 1 - Flexible copper class 5 CEI EN 60228
- 2 - PVC TI2
- 3 - PVC TM2
Characteristics:
- Rated voltage: 300/500 V
- Operating Temperature: +5°C - +60° C on the conductor
- Max. temperature of short circuit: 160° C on the conductor (max. duration 5 seconds)
-
Min. bending radius: Mobile installation: 12 x outer diameter Fixed installation: 6 x outer diameter
Applications:
| Section | Max diam. conductor | Insulation thickness | sheath thickness | Outer diameter | Max cond. resist. at 20°C | Cable weight |
| mm2 | mm | mm | mm | mm | ohms/km | kg/km |
| 7 G 1 | 0.21 | 0.6 | 1.0 | 9.4 | 19.5 | 175 |
| 10 G 1 | 0.21 | 0.6 | 1.2 | 12.2 | 19.5 | 255 |
| 12 G 1 | 0.21 | 0.6 | 1.2 | 12.6 | 19.5 | 290 |
| 14 G 1 | 0.21 | 0.6 | 1.3 | 13.4 | 19.5 | 335 |
| 16 G 1 | 0.21 | 0.6 | 1.3 | 14.1 | 19.5 | 380 |
| 19 G 1 | 0.21 | 0.6 | 1.4 | 15.1 | 19.5 | 435 |
| 24 G 1 | 0.21 | 0.6 | 1.5 | 16.7 | 19.5 | 550 |
| 27 G 1 | 0.21 | 0.6 | 1.6 | 19.3 | 19.5 | 615 |
| 7 G 1.5 | 0.26 | 0.7 | 1.2 | 11.1 | 13.3 | 240 |
| 10 G 1.5 | 0.26 | 0.7 | 1.3 | 14.2 | 13.3 | 335 |
| 12 G 1.5 | 0.26 | 0.7 | 1.4 | 14.9 | 13.3 | 390 |
| 14 G 1.5 | 0.26 | 0.7 | 1.4 | 15.6 | 13.3 | 445 |
| 16 G 1.5 | 0.26 | 0.7 | 1.5 | 16.7 | 13.3 | 515 |
| 19 G 1.5 | 0.26 | 0.7 | 1.5 | 17.5 | 13.3 | 585 |
| 24 G 1.5 | 0.26 | 0.7 | 1.7 | 20.8 | 13.3 | 745 |
| 27 G 1.5 | 0.26 | 0.7 | 1.8 | 21.5 | 13.3 | 825 |
