semi-automatic blow machine
Model Type: YC-2L-2
Product max volume:2L
Suitable for blowing bottles between 150ml to 2000ml
Necessary auxiliary devices:High pressure air compressor,Low pressure air compressor,Air filter.
|
Main machine (blowert + oven) |
Model type |
Tech data |
Product Spec |
Max. product volume(L/cav) |
2 |
Max. preform neck size(mm) |
100 |
|
Max. product diameter(mm) |
180 |
|
Max. product height (mm) |
300 |
|
Cavities |
2 |
|
Blow molding part |
Die force (KN) |
100 |
Die stroke (mm) |
270 |
|
Max. mould size(mm) |
390*345 |
|
Mould thickness |
Adjustable |
|
Mould spacing(mm) |
||
Max. pulling stroke(mm) |
400 |
|
Operation pressure(Mpa) |
0.8-1.0 |
|
|
Operation air pressure consumption (1tr/min) |
200 |
|
Blow pressure(Mpa) |
1.2-2.8 |
|
Blow air pressure consumption (1tr/min) |
300 |
|
Output(pcs/h) |
1000-1800 |
|
Machine size(LxWxH)(m) |
1.46*0.58*1.8 |
|
Machine weight(KG) |
650 |
|
Oven |
Temperature grade(rate) |
8 |
Heating time(S) |
90-200 |
|
Voltage(V) |
220 or as your request |
|
Frequency(HZ) |
50/60 |
|
Total power(KW) |
16 |
|
Oven Size (LxWxH) |
1.35*0.55*1.15 |
|
Oven weight (KG) |
300 |
Service:
Provide whole drawing for the perform mould and bottle mould. Free charge for word design on
the mould. We can help you install the machine; from setting machine, testing, and to check
the machine is on the good working condition. There is a litter charge, only for flight charge and
accommodation.
Machine Pictures
