Specifications
semi-auto plastic bottle making machine1.volume:150ml-2liter
2.cavity:4
3.output:2200-2500bph
4.High quality low price
semi-auto plastic bottle making machine
|
Main machine (blower + oven) |
Model type |
Tech data |
Product Spec |
Max. product volume(L/cav) |
2L |
Max. preform neck size(mm) |
100 |
|
Max. product diameter(mm) |
180 |
|
Max. product height (mm) |
300 |
|
Cavities |
4 |
|
Blow molding part |
Die force (KN) |
100 |
Die stroke (mm) |
270 |
|
Max. mould size(mm) |
390*345 |
|
Mould thickness |
Adjustable |
|
Mould spacing(mm) |
400 |
|
Max. pulling stroke(mm) |
400 |
|
Operation pressure(Mpa) |
0.8-1.0 |
|
|
Operation air pressure consumption (1tr/min) |
200 |
|
Blow pressure(Mpa) |
1.2-2.8 |
|
Blow air pressure consumption (1tr/min) |
300 |
|
Output(pcs/h) |
2200-2500(500ml bottle) |
|
Machine size(LxWxH)(m) |
1.86*0.88*1.8 |
|
Machine weight(KG) |
800 |
|
Oven |
Temperature grade(rate) |
8 |
Heating time(S) |
90-200 |
|
Voltage(V) |
220 or as your request |
|
Frequency(HZ) |
50/60 |
|
Total power(KW) |
32 |
|
Oven Size (LxWxH) |
1.35*0.55*1.15 |
|
Oven weight (KG) |
300 |
Semi-automatic blow moulding machine
l Use integated mic computer controler,with OMRON control chip, the response speed is very quickly and the timing very precisely. Use life durable and failure rate very low. It’s the revolutionary product of industrial control.
l High responsivenesspneumatic components, action timely and precisely
l Thorough safe operation mechanism, start-up with two hands, avoid the accident during the operation
l Infrared heating technology, safe and energy conservation, no pollution of the environment. With the 8 rates adjustable temperature controller, make the temperature suitable for blowing.
